2. PHASE 2:
SELECTING DEVICES
The second phase firms up the
implementation of the customer’s
requests and requirements by se-
lecting devices. Devices are se-
lected based on the requirements
regarding the loads to be operated,
the functions, the design require-
ments (operating stations) and, if
necessary, the installation possi-
bilities (e. g. flush-mounted or DIN
rail-mounted devices).
Evaluating installation locations
If possible, the installation loca-
tions should be evaluated during the
planning stage. DIN rail-mounted
devices need space on a sub-dis-
tributor; concrete ceilings with met-
al reinforcement attenuate the wave
propagation to a greater extent than
wooden ceilings. The same applies
to mineral plasters or cavity walls
based on metallic cavity frames.
Rules for installation locations
• Avoid shading, reflections and the
suppression of wireless signals
(e. g. due to solid ceilings and
walls).
• Keep distances between trans-
mitters and receivers short.
• Do not install transmitters and
receivers close to the ground.
• Keep distance from larger metal
surfaces such as doors, frames,
aluminium roller shutters, ceil-
ing panels, distribution cabinets,
insulating foils and ventilation
grilles.
• Keep distance from sources of
radio interference, such as elec-
tronic ballasts, motors and Tronic
transformers.
• Keep distance from other radio
services, e. g. cordless phone,
wireless headphones.
Take damp surfaces such as fresh-
ly plastered or papered walls into
consideration, because they also
attenuate wireless signals.
3. PHASE 3:
INSTALLING THE SYSTEM
If it is sufficient to connect trans-
mitters and actuators to one an-
other to implement the customer’s
requests and requirements, or
perhaps to switch the operating
mode too, the installation engineer
can choose the commissioning
method they prefer.
More comprehensive functions
offering greater convenience are
implemented with the eNet server
and the eNet SMART HOME con-
nect commissioning interface.
Manual
commissioning
eNet SMART HOME
connect
Connecting transmitters and
actuators
Switching the operating mode
Adjusting running times,
adjusting the dimming principle
Smartphone-based operation –
Advanced operating modes –
Adjusting parameters –
Smart home scenes –
+ app
If-Then rules –
+ app
Time functions –
+ app
Timing
(Astro function)
–
+ app
Documenting the system –
Diagnostic functions –
Displaying measured values –
Energy sensors –
Remote access –
+ app
Fully encrypted wireless
communication
–
Load management –
+ app
Room Where Device
Upstairs
sub-distributor
Dimming actuator,
4-gang
Living room Roller shutter on
the window
Mini blind actuator
Bathroom Underfloor heating
system
Smart thermostat
Living room Radiator Smart radiator
thermostat
Bedroom Door Wall transmitter, 3-gang
Bedroom Middle of the bed Wall transmitter, 1-gang
“Everything”
131130 eNet _ Planning and commissioning
