– 49 –
(2) List of memory switch data
No Item Setting range
U001 Soft start function 0 to 9 stitches 0: No soft start
1 - 9: Number of stitches to be sewn at the soft-start sewing
speed
U014 Sewing count function 1 to 3 1: Counter counts one when the back part of the pedal is de-
pressed to the second level.
2: Sewing counter switch input
3: Counter counts one every time the absence of material is
detected after the sewing machine has performed sewing
in the state the material is present.
U021 Presser foot goes up
when the pedal is at its
neutral position
0 to 1
U035 Lowest sewing speed by
pedal
150 to 420 sti/min
U037 Sewing speed for soft-
start function
100 to 5500 sti/min This memory switch data item is used for setting the sewing
speed to be employed while the soft-start function works.
U038 One-shot sewing speed 100 to 5500 sti/min This memory switch data item is used for setting the sewing
speed to be employed while the one-shot sewing function
works.
U039 Rotation starting position 10 to 1000 This memory switch data item is used for setting the position
from which the sewing machine starts operating by depress-
ing the pedal. (Pedal stroke)
U040 Acceleration starting
position
10 to 1000 This memory switch data item is used for setting the acceler-
ation starting position of the pedal with reference to its neutral
position. (Pedal stroke)
U041 Presser-foot lifting start-
ing position
–500 to –10 This memory switch data item is used for setting the upper
position of the presser foot by operating the pedal. (Pedal
stroke)
U042 Presser-foot lowering
starting position
10 to 500 This memory switch data item is used for setting the position
of the pedal at which the presser foot starts coming down with
reference to its neutral position.
U043 Cloth-puller lifting and
chain-o thread-cutter
operation starting posi-
tion
–1000 to –100 This memory switch data item is used for setting the position
of the pedal at which the cloth puller goes up (in the case the
pedal position at which the cloth puller goes up is set so that
it goes up after the presser foot with U206), and for setting
the position of the pedal at which the chain-o thread cutter
operates (in the case the operation of chain-o thread cutter
by depressing the back part of pedal is enabled with S043),
with reference to its neutral position. (Pedal stroke)
U044 Maximum sewing speed
position
10 to 15000 This memory switch data item is used for setting the position
of the pedal at which the sewing machine reaches its max-
imum sewing speed with reference to its neutral position.
(Pedal stroke)
U045 Pedal neutral position
correction value
–150 to 150 This memory switch data item is used for setting the neutral
position of the pedal.
U047 Presser-foot lifting end
position
–1000 to –100 This memory switch data item is used for setting the position
reached by depressing the back part of pedal to the rst level
(rst-level spring position)
U049 Presser-foot lowering
time
0 to 500 ms This memory switch data item is used for setting the time
during which the presser foot comes down.
