– 14 –
3-12. To use the sewing machine with a cloth puller for sewing heavy-to medium-weight ma-
terials
The MS-1261A has been developed to sew extra heavy-weight materials as standard.
When you use this sewing machine for sewing heavy-weight materials or medium-weight materials, it is nec-
essary to change the gauges following the procedure described below.
3-12-1. Replacing the feed dog
Remove the throat plate. Loosen screw
❶
in the
feed dog and remove the feed dog. Then, replace
the feed dog with an appropriate one.
Each of the feed dogs for heavy- to
medium-weight materials has been
designed so that it can be used only by
replacing it without adjusting the feed
dog height. However, it is really neces-
sary to adjust the feed dog height, refer
to "3-7. Adjusting the feed dog height" p.
10
★
To change the height in dierence on the
righthand side of the feed dog
Loosen two serews
❶
in the adjusting feed dog and
remove spacer
❷
(plate thickness: 0.5 mm).
Many dierent types of spacers are available.
WARNING :
Turn OFF the power before starting the work so as to prevent accidents caused by abrupt start of the
sewing machine.
3-12-2. Changing the throat plate
Detach throat plate setscrews
❶
(two pieces) and
❷
(one piece). Then, change the throat plate with an
appropriate one.
❶
❷
