– 13 –
ENGLISH
(3) MS-1261/V045 (for medium-weight materials) - Optional
Model
1234
Part name Gauge set Throat plate Feed dog (asm.) Needle thread guide
Needle gauge
Code inch mm
MS-1261
/V045
E 7/32 5.6 12972956 12972907 12975058
B1130051000
F 1/4 6.4 12972857 12972808 12974952
G 9/32 7.2 12973053 12973004 12975157
H 5/16 8.0 12973152 12973103 12975256
K 3/8 9.5 12973251 12973202 12975355
(5) MS-1261/V046
、
MS-1261M/V046 (for medium- to extra-heavy-weight materials)
Model
12345
Part name
Gauge set
(with fi nger guard)
Throat plate Needle clamp (asm.)
Presser foot (asm.)
(with fi nger guard)
Feed dog (asm.)
Needle gauge
Code inch mm
MS-1261
/V046
E 7/32 5.6 12954061 12954004 12956355 12957163 12965158
F 1/4 6.4 12953964 12953907 12956256 12957064 12965059
G 9/32 7.2 12954160 12954103 12956454 12957262 12965257
H 5/16 8.0 12954269 12954202 12956553 12957361 12965356
K 3/8 9.5 12954368 12954301 12956652 12957460 12965455
MS-1261M
/V046
E 7/32 5.6 12954665 12954608 12956355 12956165 12970059
F 1/4 6.4 12954566 12954509 12956256 12956066 12969952
G 9/32 7.2 12954764 12954707 12956454 12956769 12970158
H 5/16 8.0 12954863 12954806 12956553 12956868 12970257
K 3/8 9.5 12954962 12954905 12956652 12956967 12970356
(4) Options for V045
1. Spacer for presser foot 2. Setscrews
No.
Plate thickness
(mm)
Part No. Part name Part No. Plate
①
0.3 12973509
Presser foot
adjusting plate B
SS5060310SP
2
②
0.5 12973608
Presser foot
adjusting plate C
2
③
0.8 12973707
Presser foot
adjusting plate D
SS5060410SP
2
④
1.0 12962106
Presser foot
adjusting plate A
2
⑤
1.2 12973806
Presser foot
adjusting plate E
2
* Neither the spacer nor the spacer setscrew is included in the gauge set.
3. Spacew for feed dog
No.
Plate thickness
(mm)
Part No. Part name
①
0.3 12975702
Feed dog
adjusting plate B
②
0.5 12964102
Feed dog
adjusting plate A
③
0.8 12975801
Feed dog
adjusting plate C
④
1.0 12975900
Feed dog
adjusting plate D
Model
678
Part name Looper (L) (asm.) Looper (R) (asm.) Looper (C) (asm.)
Needle gauge
Code inch mm
Mark
No.
Mark
No.
Mark
No.
MS-1261
/V046
MS-1261M
/V046
E 7/32 5.6
12968558 1 12968855 1
12969150 1
F 1/4 6.4
G 9/32 7.2
H 5/16 8.0
12968657 2 12968954 2
K 3/8 9.5
MarkMark Mark
