− 1 −
No.
Model Specifi cations
Item MS-3580SF/1SN MS-3580SF/0SN
1 Stitch type 3-needle, 6-thread, double chainstitch machine (401 LSc-3)
2 Application Denim, working clothes, felt, etc.
3 Max. sewing speed 4,500 sti/min
4 Sewing speed 3,500 sti/min
5 Needle gauge 8 gauge: 3.2 mm, total width: 6.4 mm
6 Stitch length 2.1 to 3.6 mm (standard : 3.2 mm) at 1-inch intervals
7
Needle
(standard size)
UY130GS (standard)
140 (#22)
8 Needle bar stroke 33mm
9 Number of threads 6 pcs.
10 External dimensions H : 420 x W : 285 x D : 345 mm
11 Machine head weight 23.5kg
12
Lifting amount of
presser
Max. 9 mm (At the time of delivery from factory : 6.5 mm)
13 Feed roller width 11.9mm
14 Feed roller shape Standard (narrow type)
15 Feed adjustment
Main feed : Slide type stitch pitch adjusting system
With differential feed
lever adjusting system
Without differential feed
16 Lubrication Automatic rotary pump lubrication system
17 Lubricating oil JUKI MACHINE OIL No. 18
18 Oil tank capacity Tank capacity : 140 ml
19 Installation Table and auxiliary drive type
20
Working temperature/
humidity ranges
Temperature : 5 - 35°C, humidity: 35 - 85% (No dew condensation permissible)
21
Supply voltage/
frequency
Rated voltage ±10%, 50/60Hz
22 Noise
- Equivalent continuous emission sound pressure level (L
pA
) at the workstation :
A-weighted value of 80.0 dB; (Includes K
pA
= 2.5 dB); according to ISO 10821- C.6.2 -ISO 11204 GR2
at 3,500 sti/min.
Roller mechanism/clutch type
!
.
SPECIFICATIONS
