1. GENERAL INFORMATION

Dear customer, thank you for choosing our product. In the following, we will show you what you need to bear in mind during commissioning and use.

Should you encounter any unexpected problems during use, please do not hesitate to contact us.

2. DEVICE OVERVIEW & PIN ASSIGNMENT

Our Explorer Board is the simple and eicient way to develop your Raspberry Pi Pico projects.

With the most important components already integrated, you save time and eort when wiring. The Explorer Board has a wide range of interface connectors

so you can connect your projects to a variety of modules and devices. With the integrated breadboard, you can quickly build and realize your own projects.

Thanks to the option of switching all modules on or o individually, you can use your pins, which are also routed separately to the outside, for other projects

or experiment on the integrated breadboard at any time.

All built-in components can be switched o via the respective switch if they are not required. This means that the associated pins can also be used for other

components if necessary.

To the le and right of the Raspberry Pi Pico, all pins are additionally designed. Components can be connected directly here or routed to the integrated

breadboard via additional cables.
