control signal from the same channel number. In other words, changing the settings of one
channel will affect all the fixtures simultaneously.
If you set a different address, each unit will start to “listen to” the channel number you have set,
based on the quantity of control channels of the unit. That means changing the settings of one
channel will affect only the selected device.
In the case of the LED moving head, in 65 channel mode, you should set the starting address
of the first unit to 1, the second unit to 66 (65 + 1), the third unit to 131 (65+ 66), and so on.
DMX SET UP
DMX ADDRESSING.
All fixtures should be given a DMX starting address when using a DMX controller, so the
correct fixture responds to the correct control signal. This digital starting address is the
channel number from which the fixture starts to “listen” to the digital control signal sent out
from the DMX controller. The assignment of this starting DMX address is achieved by
setting the correct DMX address on the digital control display on the fixture.
You can set the same starting address for all fixtures or a group of fixtures, or set different
addresses for each individual fixture. Setting all fixtures to the same DMX address will
cause all fixtures to react in the same way. In other words, changing the settings of one
channel will affect all the fixtures simultaneously.
If you set each fixture to a different DMX address, each unit will start to “listen” to the
channel number you have set, based on the quantity of DMX channels of each fixture.
That means changing the settings of one channel will only affect the selected fixture.
For example, when this unit is operating in 27 channel mode, you should set the starting
DMX address of the first unit to 1, the second unit to 39 (1 + 38), the third unit to 77 (1 +
38 + 38), and so on. See the chart below for more details.
CHANNEL MODE
UNIT 1
ADDRESS
UNIT 2
ADDRESS
UNIT 3
ADDRESS
UNIT 4
ADDRESS
38 Ch(Simple)
1
39
77
115
48 Ch(Basic)
1
49
97
145
