1514
EN
SPECIFICATIONS
Electrical
Operating Voltage 14.4V DC (10V – 15.9V)
Operating Temp Range -4 F to +158 F (-20 C to +70 C)
Current Draw / Fuse Value 5 A (max) / 120 mA (standby) / 1.5 A
NMEA 2000® LEN 1 (Micro-C connector)
Compatible MFDs Simrad, Lowrance, Raymarine, Garmin
Audio Outputs/Inputs
Output Channels One stereo pair and mono subwoofer RCA plugs per zone
Output Conguration Relative, Absolute, Fixed or O
Maximum Output Voltage
Relative or Absolute: 4V RMS
Fixed: Selectable 4V/2V/1V RMS
Output Impedance 250 Ω
Auxiliary Input Channels Two stereo pairs of RCA plugs (2V/1V RMS Input Sensitivity)
Tuner
FM Tuner with RDS 87.5 MHz to 107.9 MHz (0.2 MHz step)
AM Tuner 530 kHz to 1710 kHz (10 kHz step)
DAB+ Tuner 170 MHz to 230 MHz
Favorites 24 presets across all tuners/bands
Bluetooth®
Prole A2DP v1.2, AVRCP v1.4
Core Specication Version 2.1 + EDR
Codec SBC, Qualcomm® aptX™ audio
Connection Range Up to 35 ft / 11 m
USB
Interface USB 2.0
Charging Output USB1: 1 A / USB2: 500 mA
Supported Audio Formats MP3, MP4, WAV, AAC, M4A, M4B
Apple Compatibility
iPhone SE (2nd generation), iPhone 11 Pro Max, iPhone 11 Pro, iPhone 11,
iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8
(functionality contingent upon compatible iOS release)
Dimensions
Unit W x H x D 7.70 in. x 2.32 in. x 4.96 in. (196 mm x 59 mm x 126 mm)
Advisory
Message
Description
Check Antenna
The radio has detected a fault with the SiriusXM antenna. The antenna cable may be
either disconnected or damaged.
• Verify that the antenna cable is connected to the SiriusXM Connect Vehicle Tuner.
• Inspect the antenna cable for damage and kinks. Replace the antenna if the cable
is damaged.
• SiriusXM products are available at your local audio retailer or online
at www.shop.siriusxm.com.
Check Tuner
The radio is having diculty communicating with the SiriusXM Connect Vehicle Tuner.
The tuner may be disconnected or damaged.
• Verify that the SiriusXM Connect Vehicle Tuner cable is securely connected to the radio.
No Signal
The SiriusXM Connect Vehicle Tuner is having diculty receiving the SiriusXM
satellite signal.
• Verify that your vehicle/vessel is outdoors with a clear view of the sky.
• Verify that the SiriusXM antenna is mount on the exterior.
• Move the SiriusXM antenna away from any obstructions.
• Inspect the antenna cable for damage and kinks.
• Consult the SiriusXM Connect Vehicle tuner installation manual for more information
on antenna installation. Replace the antenna if the cable is damaged. SiriusXM products
are available at your local audio retailer or online at www.shop.siriusxm.com.
Subscription
Updated
The radio has detected a change in your SiriusXM subscription status.
Press VOL/SEL to clear the message.
In the U.S.A., visit www.siriusxm.com or call 1-866-635-2349 if you have questions about
your subscription.
In Canada, visit www.siriusxm.ca or call 1-888-539-7474 if
you have questions about your subscription.
Channel
Unavailable
The channel that you have requested is not a valid SiriusXM channel or the channel you
were listening to is no longer available. You may also see this message briey when rst
connecting a new SiriusXM Connect Vehicle tuner.
Visit www.siriusxm.com for more information about the SiriusXM channel lineup.
Channel
Unsubscribed
The channel that you have requested is not included in your SiriusXM subscription
package of the channel that you were listening to is no longer included in your SiriusXM
subscription package.
In the U.S.A., visit www.siriusxm.com or call 1-866-635-2349 if you have questions about
your subscription package or would like to subscribe to this channel.
In Canada, visit www.siriusxm.ca or call 1-877-438-9677.
Channel Locked
The channel that you have requested is Locked by the radio Parental Control feature. See
Parental Controls, page 13 for more information on the Parental Control feature and how
to access locked channels.
SIRIUSXM TROUBLESHOOTING
Advisory messages may appear on the display when a SiriusXM-Connect Vehicle
Tuner is connected to the MM105-HR. Refer to the table below for an explanation and
suggested corrective actions.
