4 | JL Audio - C2-650 Owner’s Manual

Amplifier

Output

GeTTinG sTarTeD

•Turnofftheaudiosystem.Itisalso

advisabletodisconnectthenegative(–)

terminalofyourvehicle’sbatterywhenever

performinginstallationwork.

•Beforecutting,drillingorinsertinganyscrew,

checkclearancesonbothsidesoftheplanned

mountingsurface.Alsocheckforanypotential

obstacles,suchaswindowtracksandmotors,

wiringharnesses,etc.Checkbothsidesofthe

vehicle,manyvehiclesarenotsymmetrical!

•Alwayswearprotectiveeyewear.

CrossoVer neTworK insTallaTion

ThecrossovernetworkssuppliedwithyourC2

Systemshouldbeinstalledinadrylocationinside

yourvehicle.DONOTINSTALLTHEMINSIDEOF

ADOOR!Doorsoftengetwetontheinside,which

candamageyourcrossovernetworksandcould

potentiallydamageyourentiresoundsystem.The

crossoverscanbescrewedintoasolidsurfaceviatwo

holeslocatedundertheprotectivecoverofthecase.

Toaccesstheseholes,simplysqueezethesidesofthe

coverwhilegentlypullingthecoverawayfromthe

base.Makesurethatyourmountinglocationwillnot

causedamagetowiring,fuellines,brakelinesorany

othervitalcomponentofyourvehicle.Onceyouhave

screwedthecaseinandmadeyourconnections,snap

theprotectivecoverbackintoplace.



WARNING

!!

It is absolutely vital that your component system

is connected as shown in this manual. Failure to

connect the system as shown may result in damage to

your speakers which is NOT covered under warranty.

Do not substitute different crossover networks into

your C2 System. Do not use crossover networks

intended for different C2 models.

TweeTer ProTeCTion

TheC2crossovernetworksareequippedwith

anadvancedelectronictweeterprotectioncircuit

designedtominimizethepossibilityoftweeter

failure.Thiselectronicdevicemonitorscurrentgoing

tothetweeterandwilldisconnectthetweeterfrom

thesignalwhenitsensesoverload.Shouldthisoccur

whilelisteningtotheaudiosystem,simplyreducethe

volumeforafewsecondsandtheprotectioncircuit

willresetitselfautomatically.

CrossoVer neTworK aDJusTmenT

Thecrossovernetworkshavebeendesignedto

allowtonaladjustmentstothetweeterlevel.These

adjustmentsmakeitpossibletofine-tuneyoursystem

tosuityourlisteningpreferencesandtocompensate

forvariousspeakermountingapplications.
