19
2. ON THE RIGHT SIDE OF THE GO KART, ADJUST THE STEERING BRACKET AND FRONT AXLE CONNECTOR UNTIL THE TIP OF THE
STEERING BRACKET IS UNDER THE TIP OF THE FRONT AXLE CONNECTOR, AND THE HOLES IN THE TWO PIECES ARE ALIGNED.
3. FROM THE TOP, INSERT THE BOLT THROUGH THE SET OF ALIGNED HOLES UNTIL THE TIP EMERGES ON THE UNDERSIDE.
4. TWIST THE NUT CLOCKWISE ONTO THE TIP OF THE BOLT. HOLD THE NUT STEADY WHILE YOU TIGHTEN THE BOLT INTO IT BY
TURNING THE BOLT CLOCKWISE WITH THE PHILLIPS-HEAD SCREWDRIVER.
BOLT
NUT
STEERING
BRACKET
PHILLIPS-HEAD
SCREWDRIVER
FRONT AXLE
CONNECTOR
STEERING
BRACKET
FRONT AXLE
CONNECTOR
2
3
4
