Je bekijkt pagina 36 van 40
Item Part No. Description Qty.
1 JT1-596 Black Polypropylene Wheel 2
2 JT1-597 Hairpin Cotter Pin 2
3 JT1-598 Middle Mast Bottom UHMW Insert 1
4 JT1-599 Upper Mast Bottom UHMW Insert 1
5 JT1-600 Bottom UHMW Insert 1
6 JT1-601 Top UHMW Insert 1
7 JT1-602 Loop Grip Clevis Pin w/Red Handle 1
8 JT1-603 3/8-16 X 1-1/2 Hex Head Bolt; GR8 4
9 JT1-604 3/4” Side Mount Ext Snap Ring 1
10 JT1-605 1/4-20 X 1/2 Flg Hex Head Bolt; GR8 17
11 JT1-606 1/2-13 X 1-1/4 Flg Hex Head Bolt; GR8 1
12 JT1-607 1/2-20 X 3/4 Socket Set Screw 4
13 JT1-608 3/4-10 X 4-1/2 Flg Hex Head Bolt; GR8 3
14 JT1-609 5/8-11 X 5 Flg Hex Head Bolt; GR8 4
16 JT1-611 1/2-13 Flg Hex Nylock Nut; GR8 5
17 JT1-612 3/4-10 Flg Nylock Nut 3
21 JT1-616 1/2-13 X 3-1/2 Flg Hex Head Bolt; GR8 3
22 JT1-617 3/8-16 Retract. Steel Plunger (short) 1
24 JT1-619 3/8” Spring Lock Washer: GR8 4
25 JT1-620 2” Rubber Black Round Cap 2
28 JT1-623 Wheel Caster 4
29 JT1-624 Winch (RH) 1
30 JT1-1344 Oval Threaded Connecting Link Kit (4-pack) 2
31 JT1-594 Lifting Hook 1
32 JT1-1345 Turnbuckle; Clevis & Eye Kit (2-pack) 1
41 JT1-593 Safety Pin Shackle 1
42 JT1-1292 Lift Cable (55 Ft.) 1
43 JT1-1293 Guy Wire (13.42 Ft.) 2
44 JT1-1294 Guy Wire (5.31 Ft.) 2
45 JT1-1295 Mast Cable (35 Ft.) 1
46 JT1-1296 Mast Cable (18.38 Ft.) 1
48 JT1-640 1/4-20 X 1 Flg Hex Head Bolt; GR5 4
49 JT1-641 0.5 Dia Detent Pin; 2-1/4 Use Len. 4
50 JT1-642 1/2-13 X 3 Flg Hex Head Bolt; GR8 2
52 JT1-643 3/8-16 X 1 Flg Hex Head Bolt; GR8 8
53 JT1-644 1/4-20 Flg Hex Nylock Nut; GR5 4
10.6 PARTS LIST
33 | Chapter 10: Replacement Parts
