6.0 Specifications – JWL-1221VS lathe

Model number .................................................................................................................................... JWL-1221VS

Stock number .............................................................................................................................................. 719200

Motor and electricals:

Motor type ........................................................................................................................................... 120V DC

Horsepower ................................................................................................................................................ 1 HP

Phase ........................................................................................................................................................ single

Voltage ............................................................................................................................................... 115V only

Cycle .......................................................................................................................................................... 60Hz

Listed FLA (full load amps) ........................................................................................................................... 6 A

Power transfer .............................................................................................................................................. belt

On/off switch .......................................................................................................... paddle style with safety key

Power cord length .......................................................................................................................... 6 ft. (183cm)

Power plug installed ..................................................................................................................................... yes

Recommended circuit size

......................................................................................................................... 10A

Capacities:

Swing over bed ......................................................................................................................... 12.5” (318 mm)

Swing over tool rest base .......................................................................................................... 9.45” (240 mm)

Distance between spindle faces (tailstock flush with bed) ........................................................ 20.5” (520 mm)

Maximum distance between provided centers:

(tailstock flush with bed) ....................................................................................................... 18.5” (470 mm)

(tailstock protruding beyond bed end)

............................................................................... 20.5” (521 mm)

Faceplate diameter .......................................................................................................................... 3” (76 mm)

Headstock:

Spindle taper ............................................................................................................................................... MT2

Spindle thread ....................................................................................................................................... 1”- 8TPI

Spindle bore ................................................................................................................................. 3/8” (9.5 mm)

Number of spindle speed ranges ..................................................................................................................... 3

Spindle speed ranges .......................................................................................... 60-900, 110-1800, 220-3600

Number of indexing positions ......................................................................................................................... 24

Tailstock:

Quill taper .................................................................................................................................................... MT2

Maximum quill travel .................................................................................................................. 2-1/4” (57 mm)

Hole through tailstock................................................................................................................... 3/8” (9.5 mm)

Materials:

Bed ....................................................................................................................................................... cast iron

Headstock ............................................................................................................................. cast iron and steel

Tailstock ................................................................................................................................ cast iron and steel

Tool support ......................................................................................................................................... cast iron

Tool support base ................................................................................................................................ cast iron

Dimensions:

Bed width ................................................................................................................................. 6-5/8” (168 mm)

Height, floor to spindle centerline ............................................................................................ 14.75” (375 mm)

Stand footprint .................................................................................................. 30-1/2”L x 9”W (775 x 229 mm)

Tool support post diameter ........................................................................................................ 5/8” (15.9 mm)

Overall dimensions, assembled ................................................ 33.6”L x 11”W x 17.7”H (853 x 280 x 450 mm)

Overall dimensions of shipping carton ............................. 35.82”L x 14.56”W x 21.25”H (910 x 370 x 540 mm)

Weights:

Net........................................................................................................................................... 55 kg (121.25 lb)

Shipping .................................................................................................................................. 62 kg (136.69 lb)

subject to local/national electrical codes.

CAUTION: Tailstock must not protrude beyond bed to the extent that it cannot be securely locked in position

on the bed.
