13
Refrigerator Doors Panel Mounting
Attaching Door Panels
Holes positions:
A
B B
A
B B
C
D
E F
G
H
I
J
K
L
M
N
O O
P
A. 29
7
/
8
" (759 mm)
B. 13
7
/
16
" (342 mm)
C. 1/4" (6.5 mm)
D. 1
5
/
16
" (34 mm)
E. 50" (1270 mm)
F. 45
11
/
16
" (1160 mm)
G. 25
7
/
8
" (657 mm)
H. 6
1
/
16
" (154 mm)
I. 54
3
/
16
" (1377 mm)
J. 50" (507.5 mm)
K. 15
1
/
16
" (382 mm)
L. 3
15
/
16
" (100 mm)
M. 1
5
/
16
" (34 mm)
N. 1/2" (13 mm)
O. 11" (279.5 mm)
P. 253/8" (645 mm)
Panels Dimensions Single Bottom - Drawer
Panels can have thickness ranging between 3/4" (18 mm) and
1
1
/
8
" (28 mm).
Door panels can have a maximum weight 19 kg (42 lbs) and
drawer panels may be a maximum weight of 9 kg (20 lbs).
Exceeding these weights could void your warranty for any service
issues which can be attributed to overweight panels.
The hinging mechanism on refrigerator is considered to be
`Zero-clearance`. The door and drawer widths specified below
assume the minimum niche width is being used and a 1/8"
(3.5 mm) reveal is desired around the panels. Adjust your panel
dimensions accordingly to your own design criteria considering
your niche width and your reveal. Minimum distance should not be
less than 1/16" (1.5 mm).
A
B
C
D
E
A. 29
7
/
8
" (759 mm)
B. 54
3
/
16
" (1377 mm)
C. 1/4" (6 mm)
D. 25
3
/
8
" (645 mm)
E. 84" (2134 mm)
Door panel:
Width: 29
7
/
8
" (759 mm)
Height: 54
3
/
16
" (1377 mm)
Drawer panel:
Width: 29
7
/
8
" (759 mm)
Height: 25
3
/
8
" (645 mm)
If you want a 6" toe kick height then your bottom drawer panel
height would be 22".
Panel Mounting
Preparation of Door Panels
A
A. 30" (762 mm)
