STYLE 2- OVERLAY (TOP VIEW)
CUSTOM OVERLAY DRAWER PANELS
If you plan to install custom wood panels, you will
need to create the panels yourself or consult a
qualifi ed cabinetmaker or carpenter. See dimension
drawings for panel specifi cations.
IMPORTANT:
The thickness of the overlay panels must be 3/4”
(1.9 cm).
To avoid damage to the drawers, each overlay panel
must not weigh more than 10 lb (4.54 kg).
Do not exceed the height dimension for the overlay
panels. Panels that exceed the height dimension
may damage the refrigerator drawers, cabinets or
countertop.
The width of the overlay panels may vary according
to the width of the cabinet opening.
A- M4 x 32
B- Left and right brackets
8
*
Add 3/4” (1.9 cm) to the height dimension when
leveling legs are fully extended.
**
For custom panel models, this will vary.
21
5
/8"
(55 cm)
23
1
/16"
(58.6 cm)
23
7
/8"
(60.6 cm)
A
B
DRAWER WIDTH DIMENSIONS
STYLE 1- STAINLESS STEEL (TOP VIEW)
TOP AND BOTTOM OVERLAY DRAWER PANEL
DIMENSIONS:
UPPER DOOR
Bottom
15” (38 cm)
13/16”
(2.05 cm)
11/16”
(1.75 cm)
Top
11/16”
(1.75 cm)
13
7
/16” (34.2 cm)
11/16”
(1.75 cm)
Pilot hole 4 places
3/4”
(1.9 cm)
22
3
/8” (56.8 cm)
23
3
/4” (60.3 cm)
Bottom
15” (38 cm)
11/16”
(1.75 cm)
11/16”
(1.75 cm)
Top
11/16”
(1.75 cm)
12
13
/16” (32.6 cm)
1
7
/16”
(3.65 cm)
Pilot hole 4 places
3/4”
(1.9 cm)
22
3
/8” (56.8 cm)
23
3
/4” (60.3 cm)
LOWER DOOR
23
7
/8"
(60.6 cm)
21
5
/8"
(55 cm)
23
5
/8"
(60 cm)
Noir
25
47
/64"
(65.35 cm)**
Rise
26
13
/32"
(67.07 cm)**
For the installation of the customer panel, you will need
the following parts:
8 Wood screws
8 Brackets
