P6560C, P6563C
P560C,
P660C, P663C
P26T (P560C,
P660C, P6560C,
P663C, P6563C)
P560C P660C, P663C P6560C, P6563C 3"/80mm
P26T
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
P560C P660C P6560C P663C P6563C 3"/80mm P26T
BL (T-m) 3.00 4.42 4.43 4.54 4.43 2.39 –
DCR (ohms) 2.24 2.27 2.32 2.30 2.32 2.29 6.62
Mms (g) 8.70 13.61 13.94 14.34 13.94 4.66 –
Sd (sq cm) 100.3 132.7 141.0 132.7 141.0 43.0 –
Cms (µm/N) 424 325 325 301 325 162 –
Vas (l) 5.99 8.04 9.08 7.45 9.08 0.42 –
Fs (Hz) 82.9 75.7 74.8 76.6 74.8 183.2 –
Qes 1.13 0.75 .077 0.77 0.77 2.15 –
Qms 6.85 9.10 7.48 8.91 7.48 5.31 –
Qt 0.97 0.69 0.70 0.71 0.70 1.53 –
1wSPL (dB) 86.7 88.6 88.8 88.3 88.8 82.7 89.0
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
SPECIFICATIONS
P560C P660C P6560C P663C P6563C P26T
Type: 5-1/4" 2-Way 6-1/2" 2-Way 165mm 2-Way 6-1/2" 3-Way 165mm 3-Way 1" Component
Component System Component System Component System Component System Component System Tweeter
Nominal Impedance: 2 Ohms 2 Ohms 2 Ohms 2 Ohms 2 Ohms 6 Ohms
Power Handling, RMS: 75W 90W 90W 90W 90W 60W
Power Handling, Peak: 225W 270W 270W 270W 270W 180W
Frequency Response: 55Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 45Hz – 23kHz 2.5kHz – 23kHz
Sensitivity (2.83V, 1m): 92dB 94dB 94dB 94dB 94dB 94dB
GENERAL CARE: The loudspeaker grilles may be cleaned with a damp cloth. Do not use any cleaners or solvents on the grilles or the speaker cones.
WARRANTY: Power Series speakers are warranted against defects. The duration of the speaker’s warranty depends on the laws in the country in which it was purchased. Your local JBL car
audio retailer can help you determine the length of your warranty. To register your product, please visit us at www.jbl.com.
P462 P562 P662 P662S P6562 P6562S P963 P6462 P8662
BL (Тл·м) 2,76 3,04 3,51 3,66 3,43 3,73 5,41 3,00 3,47
DCR (Ом) 2,28 2,38 2,38 2,30 2,34 2,48 2,44 2,19 2,40
Mms (г) 4,86 8,16 11,79 10,73 12,49 11,95 21,83 5,78 15,27
Sd (см
2
) 56,8 100,3 132,7 132,7 141,0 141,0 237,5 56,8 158,1
Cms (мкм/Н) 300 332 301 330 282 302 422 367 238
Vas (л) 1,36 4,69 7,45 8,17 7,87 8,43 33,43 1,66 8,35
Fs (Гц) 131,8 96,7 84,5 84,6 84,8 83,8 52,4 109,3 83,5
Qes 1,20 1,28 1,21 0,98 1,32 1,12 0,60 0,97 1,60
Qms 8,21 8,12 10,58 7,86 9,47 9,12 9,70 6,46 5,95
Qt 1,05 1,10 1,09 0,87 1,16 1,00 0,56 0,84 1,26
1wSPL (дБ) 86,0 87,1 87,6 89,0 87,5 88,4 91,0 85,4 86,8
ОБЩИЕ ЗАМЕЧАНИЯ ПО УХОДУ: Решетки динамиков следует протирать влажной тканью. Не используйте чистящие средства или растворители для очистки решеток или диффузоров динамиков.
ГАРАНТИЯ: Гарантия распространяется на дефекты динамиков серии Power. Срок действия гарантии устанавливается применимым законодательством страны приобретения. Для определения
гарантийного срока обратитесь к местному продавцу автомобильной акустики JBL. Чтобы зарегистрировать продукт, посетите страницу www.jbl.com.
СПЕЦИФИКАЦИИ P462 P562 P662 P662S P6562 P6562S P963 P6462 P8662
Тип: 100 мм,
2-полосная АС
130 мм,
2-полосная АС
160 мм,
2-полосная АС
160 мм,
2-полосная АС
мал. глубины
165 мм,
2-полосная АС
165 мм,
2-полосная АС,
мал. глубины
152х229 мм,
2-полосная АС
100х152 мм,
2-полосная АС
127х178/152х200 мм,
2-полосная АС
Номинальное сопротивление: 2 Ом 2 Ом 2 Ом 2 Ом 2 Ом 2 Ом 2 Ом 2 Ом 2 Ом
Подводимая мощность, RMS: 50 Вт 55 Вт 75 Вт 55 Вт 75 Вт 55 Вт 110 Вт 50 Вт 75 Вт
Подводимая мощность, пик.: 150 Вт 165 Вт 225 Вт 165 Вт 225 Вт 165 Вт 330 Вт 150 Вт 225 Вт
Рабочий диапазон частот: 75 Гц – 23 кГц 55 Гц – 23 кГц 45 Гц – 23 кГц 55 Гц – 23 кГц 45 Гц – 23 кГц 55 Гц – 23 кГц 35 Гц – 23 кГц 75 Гц – 23 кГц 40 Гц – 23 кГц
Чувствительность (при 2,83 В/1 м): 91 дБ 92 дБ 93 дБ 93 дБ 93 дБ 93 дБ 96 дБ 91 дБ 92 дБ
Bekijk gratis de handleiding van JBL Power P662, stel vragen en lees de antwoorden op veelvoorkomende problemen, of gebruik onze assistent om sneller informatie in de handleiding te vinden of uitleg te krijgen over specifieke functies.
Productinformatie
| Merk | JBL |
| Model | Power P662 |
| Categorie | Niet gecategoriseerd |
| Taal | Nederlands |
| Grootte | 1667 MB |
