14
EN
Figure 21: Plug connectors into the sockets and move the rubber boot to cover the plug connectors if rubber boots are used.
Step 6 – Close and Secure TERMINAL COVER – Close the terminal cover and secure it with the two screws that are captive in
the TERMINAL COVER.
Figure 22:
Closing TERMINAL COVER and tightening 2 screws
Step 7 – Tighten STRAIN RELIEF clamping mechanism with the included 2 screws.
Figure 23:
Tightening the Strain Relief Clamping Mechanism (Shown with
STRAIN RELIEF on the side location and with unjacketed wires)
IMPORTANT:
Always follow building codes and regulations for the area and type of construction.
Step 8 – Remove the Protective Cover
Figure 24:
Remove the Protective Cover
