MENU
FUNCTION
PARAMETER
COMMENT
2PLR
2PTB
4P
DISPLAY FUNCTION
2P/4P LR/TB etc. RATIO
Size of the selected window can be adjusted from
0 to 4
2P/4P LR/TB etc. SWAP
SWAP windows position
SELECT REGION
2P LR LEFT
Select the region you want to changes the picture
and image parameters such as: "Contrast, Gamma,
Hue, etc..." Parameters settings should be done
in MENU "REGION ADJUST".
2P LR RIGHT
2P TB LEFT
2P TB BOTTOM
4P BOTTOM LEFT
4P TOP RIGHT
4P TOP LEFT
4P BOTTOM RIGHT
XXX FULL
INPUT
Same
Choose the input source for the active (current)
window:
D0 DP,D1 HDMI,D2 HDMI,D3 DVI,AUTO
AUDIO INPUT
Same
Choose the input audio source you want:
D0 DP,D1 HDMI,D2 HDMI,D3 DVI,AUTO
ENTER XXX MODE
Enter 4P / 2P TB / 2P LR mode
DISPLAY FUNCTION
2P PIP POSITION
Can be chosen from: LEFT TP, RIGHT TOP, LEFT
BOTTOM, RIGHT BOTTOM
User: chose vertical and horizontal from 1 to 100
2P PIP SIZE
0-10
Choose the size of the sub-window from 1 to 10
2P PIP SWAP
Swap windows input
2P PIP
SELECT REGION
2P PIP MAIN
Select the region you want to changes the picture
and image parameters.
2P PIP SUB
INPUT
2P PIP MAIN INPUT
Choose input from: D0 DP,D1 HDMI,D2 HDMI,D3
DVI,AUTO
2P PIP SUB INPUT
AUDIO INPUT
2P PIP MAIN INPUT
Choose input from: D0 DP,D1 HDMI,D2 HDMI,D3
DVI,AUTO
2P PIP SUB INPUT
10
