86
CARE AND MAINTENANCE
Cleaning the Hook Area
Clean the hook area at least once a month.
The caution message for cleaning the bobbin case and
the hook race will be displayed when a certain time
(10 hours) passes if “Clean Bobbin Holder Message
displayed every 10 hours” option is turned on (refer to
page 77).
1.
Turn the power switch OFF and unplug the machine.
Remove the needle and embroidery foot P (refer to
pages 12, 13).
Remove the needle plate by turning the setscrews
with the screwdriver.
Take out the bobbin and bobbin holder.
(1) Setscrews
(2) Needle plate
(3) Bobbin holder
2.
Clean the bobbin holder with a lint brush.
Apply a few drops of the bobbin holder cleaner
(included in the standard accessories) to a soft cloth
and wipe the bobbin holder thoroughly both inside
and outside.
(4) Lint brush
(5) Soft cloth
(6) Bobbin holder cleaner
3.
Clean the auto thread cutter device and around the
bobbin thread remaining sensor with the lint brush.
(7) Auto thread cutter device
(8) Bobbin thread remaining sensor
4.
Clean the hook race with a soft cloth.
(5) Soft cloth
5.
Insert the bobbin holder so that the knob ts next to
the stopper in the hook race.
(9) Knob
(10) Stopper
Attach the needle plate, presser foot and needle.
Insert the bobbin.
WARNING:
• Turn the power switch OFF and unplug the machine
before cleaning.
• Do not dismantle the machine in any way other than
as explained in this section.
CAUTION:
• Do not store the machine in a high-humidity area,
near a heat radiator, or in direct sunlight. Store the
machine in cool dry place.
• Clean the outside of the machine with a soft cloth.
• Do not use chemical solvents.
(3)
(3)
(4)
(4)
(3)
1.
2.
3.
4.
(5)
(7)
(8)
(6)
(1)
(2)
(10)
(9)
5.
(5)
