67
(2)
Embroidery area
200 mm or less
Opening width
200 mm or wider
1.
(3)
2.
(4)
Free-Arm Embroidery (optional)
The free-arm embroidery hoop FA10e/FA5e is specially
designed for embroidering tubular garments such as
sleeves, pant legs etc.
Check the opening size of the tubular portion of the
garment. The opening width must be 200 mm (8˝) or
wider.
The embroidery area should be within 200 mm (8˝) from
the opening.
Opening width:
If the opening width is 200 mm - 250 mm, the embroidery
area should be limited in order to prevent fabric from
restraining hoop movement.
Example:
Baby and Child Design #5 with FA10e free-arm
embroidery hoop
1.
Draw centerlines on the fabric with tailor’s chalk.
(1) Centerlines
2.
Open the editing window and select the FA10e free-
arm embroidery hoop. (FA10e: 100 mm x 40 mm).
Press the home key to open the embroidery window.
(2) Hoop selection key
(3) Home key
(4) FA10e: 100 mm x 40 mm
(5)
3.
(1)
3.
Press the design category key to select the Baby and
Child Design #5.
(5) Design category key
4.
Press the opening width key in the editing window to
show the embroidery area window.
Press the “+” or “–” key to adjust the opening width.
Press the OK key in the embroidery area window.
Press the X key to return to the previous page.
(6) Opening width key
(7) “+”, “–” key
(8) OK key
(9) X key
Press the OK key after editing and a message will
appear to conrm the hoop size.
(10) OK key
4.
(6)
(7)
(8) (9)
(10)
NOTE:
• If the opening width is set to less than 250 mm,
automatic thread trimming for jump threads will be
disabled, even if “Thread Cutting” in the embroidery
settings is set to anything other than “OFF” (refer to
page 82).
• Settings for the embroidery area is not available
when using the FA5e free-arm embroidery hoop.
The automatic thread cutting for jump threads is
always disabled.
