55
Selecting a pattern
To select the pattern to edit, press on the pattern image
in the editing window.
A green frame appears around the selected pattern.
(1) Green frame
(3)
Editing Window Information
The editing window contains the following keys. Press
the next/previous set key to switch the editing tools.
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(1)
(1)
(3)
(6)
(7)
(16)
(17)
(18)
(19)
(20)
(21)
(4) (5)
(4)
(2)
(2)
NOTE:
Some keys may not be available depending on the
selected pattern or settings.
(1) Next/Previous set key
(2) Page keys (refer to page 55)
(3) Jog keys (refer to page 55)
(4) Zoom key (refer to page 57)
(5) Scroll key (refer to page 57)
(6) Hoop selection key (refer to page 54)
(7) Duplicate key (refer to page 56)
(8) Delete key (refer to page 56)
(9) Resize key (refer to page 57)
(10) Rotate key (refer to page 58)
(11) Horizontal mirror image key (refer to page 58)
(12) Vertical mirror image key (refer to page 58)
(13) Arc key (refer to page 59)
(14) Group key (refer to page 60)
(15) Center position key (refer to page 55)
(16) Corner layout key (refer to page 61)
(17) Custom color key (refer to page 62)
(18) Sewing order key (refer to page 64)
(19) Color group key (refer to page 65)
(20) Single color sewing key (refer to page 66)
(21) Save le key (refer to page 66)
Moving a pattern
To move the embroidery pattern in the editing window,
press and drag the pattern to a desired location with the
touch screen stylus.
You can also move the selected pattern by pressing the
jog keys.
Press the jog keys to move the pattern to the desired
position in the editing window.
Press the center position key to move the pattern to the
center of the editing window.
(3) Jog keys
(4) Center position key
NOTE:
• Do not drag the pattern on the screen with a sharp
pointed object.
• The carriage will not move when you press the jog
keys since the pattern position will move relative to
the hoop, not to the machine.
NOTE:
If multiple patterns are placed close to each other and
it is difcult to select the desired pattern. Use the page
keys to select the pattern you want to edit.
(2) Page keys
