16
Machine Operating Buttons
(1) Start/stop button
Press this button to start or stop the machine.
The machine starts running slowly for the rst few
stitches, then runs at the speed set by the speed control
slider. The machine runs slowly as long as this button is
pressed.
The button will turn red when the machine is running, and
blue when it has been stopped.
Pressing and holding this button while sewing will slow
down the sewing speed and the machine will stop when
the button is released.
(2)
Re
verse button
•
W
hen the following stitch patterns are selected:
Utility Quilt Bridge
The machine will sew in reverse as long as the reverse
button is pressed. Release the button to sew forward.
When the machine is stopped and foot control is
disconnected, the machine will sew in reverse slowly
as long as the reverse button is pressed. Release the
button to stop the machine.
•
When any other stitches are selected:
If you press the reverse button when sewing any other
patterns, the machine will immediately sew locking
stitches and automatically stop. When the reverse
button is pressed while the machine is stopped, the
machine will immediately sew locking stitches and
automatically stop after the machine is started.
(3)
Auto-lock button
•
W
hen the following stitch patterns are selected:
Utility Quilt Bridge
Press the auto-lock button to sew a locking stitch
immediately. The machine will automatically stop.
When the auto-lock button is pressed while the
machine is stopped, the machine will immediately
sew locking stitches and automatically stop after the
machine is started.
(1)
(3)
(4)
(2)
(5)
NOTE:
• The start/stop button cannot be used when the foot
control is connected to the machine.
• You can select the desired start-up speed from
1 to 5 by pressing the corresponding key (refer to
page 171).
NOTE:
There will be particular functions of the reverse button
when stitch pattern U2, U3, B13 or B14 is selected.
Refer to pages 46-47, 76 and 78 for instructions.
(4) Needle up/down button
Press this button to bring the needle bar up or down.
The machine will stop with the needle in down position.
However, you can change the needle stop position in the
machine setting mode (refer to page 170).
(5) Thread cutter button
After nishing sewing, press this button to trim the
threads. The needle bar automatically rises after trimming
the threads (refer to page 43).
After using auto thread cutting or threading the bobbin
holder, you can start sewing without drawing up the
bobbin thread.
NOTE:
•
T
he thread cutter button does not function:
- directly after turning ON the power.
- when the presser foot is raised with the presser
f
oot lifter.
- after being pressed 3 times in a row.
•
U
se the thread cutter on the face cover if the thread
is #30 or thicker (refer to page 43).
•
When any other stitches are selected:
Press the auto-lock button to sew a locking stitch
at the end of current pattern. The machine will
automatically stop.
When the machine is stopped, press the auto-lock
button to sew a locking stitch at the end of current
pattern and the machine will automatically stop after
the machine is started.
The machine will trim the threads automatically after
locking the stitch when the auto thread cutting is
turned on (refer to page 170).
