4
Extension Table
The extension table provides an extended sewing area
and can be removed for free arm sewing.
1 Extension table
To detach:
Draw the table out to the left.
To attach:
Slide the table on the base and push the table to the
right.
Free-arm sewing
Free-arm sewing is used for stitching sleeves, waist-
bands, pant legs or any other tubular garments.
It is also useful for darning socks or mending knees or
elbows.
Accessories Storage
The accessories can be conveniently stored in the foot
storage compartment under the top cover and in the
extension table.
Under the top cover
1 Zipper foot E
2 Overcasting foot C
3 Zigzag foot A
4 Clear view foot
5 Open-toe foot
6 Convertible free motion quilting foot QB-H
7 Satin stitch foot F
8 Blind hemming foot G
9Touch panel stylus
In the extension table
10 Rolled hem foot D
11 Overedge foot M
12 1/4” seam foot O
13 Button sewing foot T
14 Cording foot H
15 Bobbins
16 Screwdriver key
17 Dual feed foot AD
18 Automatic buttonhole foot R
19 Rear compartment
NOTE:
Other accessories can be stored in the rear
compartment.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1
