57
Round end and fine fabric buttonholes
Machine settings
Pattern: 25 or 26 (Buttonhole)
Thread tension: AUTO
Presser foot: Automatic buttonhole foot R
Foot pressure: 7
The sewing procedure is the same as the square
(sensor) buttonhole (refer to pages 51-53).
The machine will sew a buttonhole in the order shown.
NOTE:
The buttonhole width can be adjusted from 2.5 to 5.5.
The stitch density can be adjusted from 0.30 to 1.00.
Keyhole buttonholes
Machine settings
Pattern: 27, 28, 29 (Buttonhole)
Thread tension: AUTO
Presser foot: Automatic buttonhole foot R
Foot pressure: 7
The sewing procedure is the same as the square
(sensor) buttonhole (refer to pages 51-53).
The machine will sew a buttonhole in the order shown.
Use an eyelet puncher to open a keyhole buttonhole.
NOTE:
The buttonhole width can be adjusted from 5.5 to 7.0.
The stitch density can be adjusted from 0.30 to 1.00.
