17
Threading the Machine
Raise the presser foot. Press the needle up/down position
button twice to raise the needle.
Turn the power switch off.
Pass the thread in order from z to m.
z Hold the thread with both hands and pass the thread
into the guide slot.
1 Guide slot
x Draw the thread to the left and around the corner of
the guide toward you.
Pull the thread along the channel.
2 Corner of the guide
3 Channel
c Draw the thread down along the right channel and
around the bottom of the thread guide plate.
Pull the thread up along the left channel.
4 Right channel
5 Thread guide plate
6 Left channel
v While holding the thread at the spool, firmly draw the
thread up and to the back of the take-up lever. Draw
the thread forward to draw it into the eye of the take-up
lever.
7Eye of the take-up lever
b Then pull the thread down along the left channel
and through the lower thread guide.
8 Lower thread guide
n Slide the thread behind the needle bar thread guide
from the left.
9 Needle bar thread guide
m Thread the needle with the needle threader (refer to
the next page).
1
2
3
4
9
8
7
6
z
c
x
b
v
5
n
z
c
x
b
v
n
m
