10
To remove the bobbin case from the shuttle,
pull open the latch of the bobbin case. Pull
the bobbin case straight out of the shuttle.
Bobbin case
Latch
Bobbin Winding
• Removing bobbin case
Remove the extension table from the machine
by pulling it to the left. Open the shuttle cover
by pulling down the tab on the left of the cover.
Raise the needle to its highest position by
rotating the handwheel toward you.
Shuttle cover
1
2
• Removing the bobbin
To remove the bobbin, release the latch and
the bobbin will drop out of the bobbin case as
illustrated.
Bobbin
1
2
3
4
3
3
4
