800-CT24 module www.janitza.com
22
Basic device
Module 1
System information
ESC
Fig.: System information window with the en-
tries of the basic device and module 1.
INFORMATION
· The permitted number of modules of the type 800-
CT24 is determined by the number of free module
slots in the suitable basic device(s) (see “Tab. Suit-
able basic devices” on p. 2).
· Option: The basic device and the connected mod-
ules can be renamed in the GridVis
®
software.
4.3 Checking module communication
After installing your module, check the function of
the communication between the basic device and
the module using the display on the basic device as
follows:
· When you are in the Home measuring display of the
basic device, pressing the button 1ESC takes you
to the Menu window.
· Use buttons 2 (5) and 5 (6) to select the menu
item System information and confirm with button 3
Enter.
· The System information window with the items
Basic device and Module 1 appears.
· The basic device has detected module 1.
4.4 System information on the module
To obtain information about a module in your mea-
surement device and module topology, proceed as in
the following example - Basic device with 3 mod-
ules - described below:
· When you are in the Home measuring display of the
basic device, pressing the button 1ESC takes you
to the Menu window.
· Use buttons 2 (5) and 5 (6) to select the menu
item System information and confirm with button 3
Enter.
· The System information window with the items
Basic device, Module 1, Module 2 and Module 3
appears.
Basic device
1. Module
2. Module
3. Module
System information
ESC
Type
Serial no.
Position
800-CT24
48 0 0 0111
3
3. Module info 1/2
ESC
Fig.: System information window with the items of
the measurement device and module topology
· Use buttons 2 (5) and 5 (6) to select, for example,
the item Module 3 and confirm with button 3 Enter.
· The Module 3 Info 1/2 window with the items Type,
Serial number and Position appears.
Fig.: Module 3 Info 1/2 window
