Tempstar HH Series Technical Manual 7610-002-23-32
Issued: 09/14/2007 Revised: N/A
SECTION 5: PARTS SECTION
CANTILEVER ARM/DOOR ASSEMBLIES (CONTINUED)
26
ITEM QTY DESCRIPTION Mfg. No.
1 1 Cantilever Arm 05700-031-92-44
2 2 Sleeve, Cantilever Arm 05700-000-85-69
3 2 Screw, 1/4"-20 x 1 1/2" Long Hex Head 05305-274-23-00
4 4 Washer, 1/4" ID S/S 05311-174-01-00
5 4 Locknut, 1/4"-20 S/S Low Profile with Nylon Insert 05310-374-02-00
6 4 Plug, Cantilever 05340-011-35-00
7 2 Connecting Link 05700-021-92-45
8 2 Spring Pin, 1/4" x 1 1/8" Long 05315-407-06-00
9 2 Yoke Assembly 05700-000-75-77
10 2 Nut, 3/8"-16 S/S Hex Locking 05310-256-04-00
11 2 Rod, Spring Connecting 05700-002-00-91
12 4 Plate, Spring Multiplier 05700-002-00-88
13 4 Spring, Cantilever Door 05340-111-35-22
14 4 Bolt, Cantilever Hanger Eye 3/8"-16 05306-956-05-00
15 4 Washer, Impeller 05311-176-02-00
16 8 Nut, 3/8"-16 S/S Hex 05310-276-01-00
* 2 Door, Upper, Left and Right Assemblies 05700-002-01-30
17 2 Door, Upper, Left and Right Weldment 05700-002-29-59
18 4 Glide, Upper Door 05700-002-00-83
* 1 Door, Lower, Right Assembly 05700-002-01-33
19 1 Door, Lower, Right 05700-031-76-80
20 2 Glide, Lower Door 05700-002-23-64
21 1 Door Stop Magnet Assembly 06401-003-08-68
* 1 Door Stop Magnet Weldment 05700-002-01-27
* 1 Magnet 05930-111-69-25
* 2 End Cap 05700-011-60-92
22 6 Wear Button 05700-011-88-01
23 20 Screw, 1/4"-20 x 5/8" 05305-274-24-00
24 20 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00
25 2 Screw, 1/4"-20 x 1/2" Long Hex Head 05305-274-02-00
26 2 Spacer, PB Bolt 05700-000-29-40
27 2 Bracket, Door Connector 06401-003-08-75
28 1 Handle, Front Door Weldment 06401-003-08-67
* 1 Door, Lower, Front Assembly 05700-002-01-31
29 1 Door, Lower, Front 05700-031-76-77
30 2 Glide, Lower Door 05700-002-23-64
* 1 Door, Upper Front Assembly 05700-002-24-92
31 1 Door, Upper, Front Weldment 05700-002-29-57
32 2 Glide, Upper Door 05700-002-00-83
* 1 Door, Lower, Left Assembly 05700-002-01-32
33 1 Door, Lower, Left 05700-031-76-79
34 2 Glide, Lower Door 05700-002-23-64
35 6 Door Stop Weldment 05700-002-29-60
36 1 Door Stop 06401-003-08-69
37* 2 Cantilever Arm Support Bracket 09515-003-15-64
38* 6 Wear Button 05700-011-88-01
