Tempstar HH Series Technical Manual 7610-002-23-32
Issued: 09/14/2007 Revised: N/A
SECTION 5: PARTS SECTION
SIDE MOUNT CONTROL BOX ASSEMBLY (CONTINUED)
23
ITEM QTY DESCRIPTION Mfg. No.
1 1 Bracket, Electrical Box Mounting 05700-002-18-48
2 9 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00
3 9 Washer, 1/4"-20 I.D. S/S 05311-174-01-00
4 1 Control Box Weldment, Right Hand 05700-002-06-48
4 1 Control Box Weldment, Left Hand 05700-002-23-08
5 2 Contactor, 4 Pole 220V 1 Phase (Only 1 for No Booster and Steam Models) 05945-109-01-69
6 4 Screw, 10-32 x 1/2" Phillips Pan Head with Washer 05305-002-32-37
7 1 Liquid Level Control 06680-200-08-21
8 3 Screw, 6-32 x 5/8" 05305-011-39-85
9 1 Thermometer, 48 Lead, Wash 06685-111-68-48
1 Decal, Wash 150 Deg. 09905-002-97-61
10 1 Relay, 240V, 50/60HZ, Top Mount 05945-002-47-74
11 8 Screw, 6-32 x 3/8" SEMS with External Tooth Washer 05305-002-25-91
12 1 Decal, Control Box Gauge 09905-002-10-69
13 1 Thermometer, 96 Lead Rinse 06685-111-68-49
1 Decal, Rinse 180 Deg. 09905-002-97-62
14 1 Timer, 4CKT 208-230V Single REV (Shown) 05945-303-31-00
14 1 Timer, Universal 05945-003-07-48
1 Timer Bracket 05700-003-02-08
6 Holder, Keystone 05940-002-21-87
1 Keying Plug 05940-003-11-66
2 Connector 05940-003-11-65
15 1 Contactor, 2 Pole 220V 20AMP( 208-230 Volt Unit Only) 05945-002-74-20
16 3 Screw, 10-32 x 3/8" Phillips Pan Head 05305-173-26-00
17 1 Timer, Cycle Delay 05945-002-13-78
18 1 Terminal Block, 3 Pole 05940-011-48-27
19 1 Decal, L1, L2, L3 09905-101-12-66
20 1 Decal, Copper Conductors 09905-011-47-35
21 4 Locknut, 10-24 S/S Hex with Nylon Insert 05310-373-01-00
22 1 Wire Lug 05940-200-76-00
23 1 Decal, Ground 09905-011-86-86
24 1 Holder, Fuse 05920-401-03-14
25 1 Cover, Control Box Weldment 05700-002-06-52
26 4 Bolt, 10-32 x 1/2" Slotted Truss 05305-173-04-00
27* 1 Switch, 8 Button Tap Touch 05930-001-99-51
28* 1 Spacer, Switch Panel 05700-002-50-02
29 1 Decal, Control Box Cover 09905-002-00-45
30 1 Light, Red 05945-504-07-18
31 1 Light, Green Indicator 05945-504-08-18
32 1 Light, Amber 05945-504-06-18
33* 1 Cover, Dielectric Control Panel 05700-021-50-89
34 1 Contactor, 2 Pole 220V 20AMP (460 Volt Unit Only) 05945-002-65-00
35 1 Overload (460 Volt Unit Only) 05945-002-65-01
* Represents an item not shown.
