Tempstar HH Series Technical Manual 7610-002-23-32
Issued: 09/14/2007 Revised: N/A
SECTION 5: PARTS SECTION
TOP MOUNT CONTROL BOX ASSEMBLY (CONTINUED)
21
ITEM QTY DESCRIPTION Mfg. No.
1 1 Control Box Weldment 05700-003-30-14
2 1 Timer Bracket 05700-003-02-08
5 2 Locknut, 6-32 S/S Hex with Nylon Insert 05310-373-03-00
6 2 Contactor, 4 Pole 220V 1 Phase (Only 1 for No Booster and Steam Models) 05945-109-01-69
7 1 Terminal Block, 3 Pole 05940-011-48-27
8 19 Locknut, 10-24 S/S Hex with Nylon Insert 05310-373-01-00
*9 1 Contactor, 2 Pole 220V 20AMP (208-230 Volt Unit Only) 05945-002-74-20
10 1 Switch, 8 Button Tap Touch 05930-001-99-51
13 1 Relay, 240V Magnecraft A 283 x CXC3-240A 05945-002-47-74
14 1 Light, Green 05945-111-44-43
15 1 Light, Red 05945-11144-45
16 1 Thermometer, 96 Lead Rinse 06685-111-68-49
17 1 Thermometer, 48 Lead Wash 06685-111-68-48
18 1 Light, Amber 05945-111-44-44
19 1 Decal, Wash 150 Deg. 09905-002-97-61
20 1 Decal, Rinse 180 Deg. 09905-002-97-62
21 1 Wire Lug 05940-200-76-00
22 1 Bracket, Liquid Level Control Mounting 05700-002-13-22
23 1 Liquid Level Control 06680-200-08-21
25 3 Screw, 6-32 x 5/8" 05305-011-39-85
26 2 Spacer, Switch Panel 05700-002-50-02
30 1 Clamp, Nylon Hose .25 - .312 05975-002-61-43
31 1 Decal, Warning-Disconnect Power 09905-100-75-93
32 1 Cover, Control Box 05700-002-23-03
33 1 Decal, Control Box 09905-003-21-90
34 4 Lockwasher, #10 Internal Tooth 05311-273-03-00
35 4 Screw, 10-32 x 3/8" Phillips Truss Head 05305-173-12-00
36 1 Decal, Copper Conductors 09905-011-47-35
37 1 Decal, Ground 09905-011-86-86
38 1 Decal, L1, L2 09905-002-78-67
39 1 Bracket, Fuse Strip Holder 05700-002-42-03
40 1 Holder, Fuse, 6 Pole 05920-002-42-13
41 1 Timer, Universal 05945-003-33-09
42 1 Decal, Dispenser Connection 09905-003-34-09
43 4 Screw, 10-32 X 1 Phillips Pan Head 05305-002-19-42
44 4 Locknut, 10-32 S/S Hex with Nylon Insert 05310-373-02-00
*45 1 Overload, TK-ONY, (460 Volt Unit Only) 05945-002-65-02
*46 1 Motor Contactor, SC-03Y, (460 Volt Unit Only) 05945-002-65-00
*47 1 Din Rail 2-3/4” (460 Volt Unit Only) 05700-001-84-65
* For a 460V Unit, Replace item 9 with items 45, 46 & 47.
