56
07610-004-33-05-B
ITEM QTY DESCRIPTION PART NUMBER
1 1
Tub Weldment, 23" Side-Loader L-R
Tub Weldment, 23" Side-Loader R-L
Tub Weldment, 30" Side-Loader L-R
Tub Weldment, 30" Side-Loader R-L
05700-003-84-59
05700-003-84-58
05700-003-88-46
05700-003-88-39
2 1 Rack Support L-R 05700-003-90-00
3 1 Strainer 05700-021-85-10
4 1 Pawl Bar Drive Linkage (see side-loader drive linkage page) 05700-003-84-78
5 1 Actuator Switch Assembly 05700-003-89-96
6 2 Leg Socket 05700-002-56-14
7 2 Support Leg 05700-021-87-59
8 2 Foot, Adjustable 05340-108-01-03
9 1 Gutter, Pawl Bar 05700-021-66-86
10 1 Guide Block Top-Slotted 05700-011-69-49
11 1 Guide Block Bottom-Slotted 05700-011-69-50
12 1 Gasket, Drive Gutter 05330-011-68-55
13 1 Bracket, Loader Pawl Bar Support 05700-003-87-39
14 16 Washer, 1/4" S/S 05311-174-01-00
15 4 Bolt, 1/4-20 x 1/2" Long 05305-274-02-00
16 39 Locknut, 1/4-20 Hex w/Nylon Insert 05310-374-01-00
17 2 Roller 05700-011-68-16
18 2 SRackStar® , 1/4-20 x 1-3/4" Long Hex Head 05305-274-10-00
19 2 Roller Shaft 05700-011-68-14
20 1 Bracket, Limit Switch 05700-021-71-18
21 1 Terminal Board 05940-011-84-41
22 1 Switch Assembly, Side-Loader, 24VDC 05700-003-87-43
23 1 Cover, Side-Loader Switch 05700-003-87-41
24 2 Locknut, 6-32 Hex w/Nylon Insert 05310-373-03-00
25 *NOTE Drain Hose, Polybraid 1" (*SEE NOTE ON PG. 54) *04720-011-69-16
26 2 Hose Clamp (Range: 13/16" to 1-1/2") 04730-719-06-09
27 1 Drain Fitting Weldment 05700-021-84-61
28 1 Tee, 1-1/2" Brass 04730-011-69-93
29 1 Nipple, 1-1/2" Close Brass 04730-207-40-00
30 1 Elbow, 90 Deg Street, Brass 1-1/2" 04730-206-32-00
31 *NOTE Conduit, 1/2" Flex 2 (*SEE NOTE ON PG. 54) *05975-003-33-36
32 3 Clamp, 1" Nylon 04730-002-41-88
33 2 Fitting, 1/2" Straight Twist/Snap 05975-003-33-27
SIDE-LOADERS
PARTS
