53
07610-004-33-05-B
PARTS
MOTOR OVERLOADS
WASH MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-111-68-40 RT1M
230 05945-111-68-40 RT1M
DRIVE MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-111-68-39 RT1G
230 05945-111-68-39 RT1G
PRE-WASH MOTOR
VOLTAGE
PART NUMBER GE PART NUMBER
208 05945-003-76-28 MT03M
230 05945-003-76-28 MT03M
460 05945-003-76-26 MT03K
WASH MOTORS: Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
• Determine the Full Load Amps (FLA) for the wash motor.
• Set the overload at the closest setting without going over for the FLA of the motor.
• The overload already compensates for the FLA and will have a setpoint that is 125% of the FLA. (Example: Wash motor
is rated at 10.0 FLA on the data plate. The replacement MT03* overload will be set at 10.0. It will trip at 12.5 Amps.)
Blue selector switch should be
set to H for manual reset.
DRIVE MOTORS: Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
• Determine the FLA for the drive motor.
• Set the overload at the closest setting without going over for the FLA of the motor.
• The overload already compensates for the FLA and will have a setpoint that is 125% of the FLA. (Example: Drive motor
is rated at 1.0 FLA on the data plate. The replacement MT03* overload will be set at 1.0. It will trip at 1.25 Amps.)
Blue selector switch should be
set to H for manual reset.
PRE-WASH MOTORS: Overloads are specied for 3-phase units only.
For GE brand MT03* series overloads, the process for setting is as follows:
• Determine the FLA for the pre-wash motor.
• Set the overload at the closest setting without going over for the FLA of the motor.
• The overload already compensates for the FLA and will have a setpoint that is 125% of the FLA. (Example: Pre-wash
motor is rated at 6.0 FLA on the data plate. The replacement MT03* overload will be set at 6.0. It will trip at 7.5 Amps.)
Blue selector switch should be
set to H for manual reset.
NOTE: Connections should be tightened to 7 in-lbs.
