DRIVE ASSEMBLY
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Drive Casting, Top 09515-004-17-06
2 1 Gasket, Drive Casting 05330-004-20-31
3 4 Screw, 1/4-20 x 1 1/2" Flat 05305-011-44-50
4 1 Drive Casting, Bottom 09515-004-17-03
5 1 Drive Shaft 05700-004-29-79
6 1 Gasket, Drain Seat 05700-002-04-42
7 4 Screw, 10-32 x 1 3/4" 05306-003-92-52
8 1 Drive Shaft Cover 05700-004-29-46
9 1 Clutch-Drive, 3/4" x 3/4" 06105-004-29-41
10 1 Drive Plate Cover 05700-004-29-49
11 1 Washer, Bonded Sealing 1/4" x 3/4" 05311-002-77-79
12 1 Collar, Shaft Drive 05700-004-29-45
13 1 Motor Plate 05700-004-19-38
14 1 Motor Support Plate 05700-004-26-97
15 1 Gasket, Clutch 05330-004-28-88
16 1 Seal, Viton Oil Shaft 3/4" ID 05330-004-29-06
17 1 Drive Motor 06105-004-29-53
18 4 Bolt, 1/4-28 x 1" S/S Hex Head 05306-004-30-91
19 1 Collar, Shaft 3/4" (Clamp-On) 03120-004-33-50
20 1 Key, 3/16" x 9/10" Long 05700-011-89-17
21 3 Bearing, Thrust 3/4" Shaft x 1-1/4" ID 03120-004-37-10
22 1 Sealing Pan Head Phillips 05305-004-26-70
