ELECTRIC BOOSTER & PLUMBING
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1
Heater, 27 kW, 208 V, 3 PH Booster
Heater, 27 kW, 230 V, 3 PH Booster
Heater, 27 kW, 460 V, 3 PH Booster
04540-500-05-00
04540-500-07-00
04540-500-12-00
2 1
Booster Hose, Top, L-R
Booster Hose, Top, R-L
05700-004-72-47
05700-004-76-41
3 1
Booster Hose, Bottom, L-R
Booster Hose, Bottom, R-L
05700-004-72-45
05700-004-76-43
4 1 Frame, Electrical Section 05700-004-62-76
5 1 Bracket, Booster Piping 05700-004-85-39
6 1 Elbow, 3/4” 90-degree Brass 04730-206-13-00
7 5 Nipple, 3/4" x 1 3/8" Brass 04730-207-34-00
8 1 Solenoid Valve, 3/4" 04810-100-53-00
9 1 Tee, 3/4” x 3/4” x 3/4” Brass 04730-211-01-34
10 1 Elbow, 3/4” 90-degree Brass 04730-206-04-34
11 1 Y-strainer, 3/4" Brass 04730-717-02-06
12 1 Union, 3/4" 04730-212-05-00
13 1 Water Inlet Riser Assembly 05700-004-63-09
14 1 Pressure Regulating Valve, 3/4" 06685-011-58-22
Complete Water Inlet Assembly
L-R 05700-004-63-10
R-L 05700-004-76-39
Contains items 5-14 above.
