07610-004-81-74-A
40
WASH CONTROL BOX
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Terminal Board 05940-002-78-97
2 1 Thermostat 05930-004-33-12
3 30 Nut, Hex 10-32 05310-004-40-48
4 18 Screw, 10-32 x 3/4" 05305-011-62-17
5 4 Screw, 6-32 x 1 3/4" 05305-004-36-67
6 4 Nut, Lock 6-32 Hex with Nylon Insert 05310-373-03-00
7 1 Terminal Block, 3-pole 05940-011-48-27
8 1 Relay, 2-Pole 05945-111-35-19
9 3 Din-rail, 3" 05700-011-84-65
10 1 Bushing, Snap 05975-003-10-46
11 1 Bracket, Thermostat 05700-004-36-37
12
4
4
Nut, 6-32 Plated
Screw, 6-32 x 1/2"
05340-118-04-00
05305-004-23-63
13 1 Contactor, AC, 120 V 05945-002-65-98
14 1 Foam Insulation (Back of Box, Not Shown) 05700-004-61-45
15 1 Overload 05945-004-25-81
16 1 Panduit Bottom, 1 1/2" x 3" x 10" 05700-004-65-17
17 1 Panduit Bottom, 1 1/2" x 3" x 8" 05700-004-65-18
18 1 Fan 05999-004-19-46
19 1 Control Box 05700-004-73-68
20 2 Connector, 16-pin Mount 05940-004-73-27
21 2 Connector, 10-pin Mount 05940-004-73-28
22 2 Connector, 8-pin Mount 05940-004-73-29
23 1 Fitting, 1/2", 90-degree 05975-003-35-32
24 2 Connector, 16-pin Receptacle 05940-004-73-43
25 2 Connector, 8-pin Receptacle 05940-004-73-44
26 2 Connector, 10-pin Receptacle 05940-004-73-45
27 2 Cover, Heater 05700-004-73-71
28 1 Cover, Control Box 05700-004-74-07
29 1 Fitting 05975-011-49-03
30 1 Contactor, AC, 100 V 05945-004-25-78
31 2 Fitting, Nut and Cap 05975-205-43-00
