07610-004-81-74-A
37
PRE-WASH ARMS & DRAIN PLUMBING
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Wash Manifold, Upper 05700-003-73-66
2 12 Cap, Threaded 04730-603-12-00
3 1 Tube, Wash System Riser 05700-004-57-20
4 1 Wash Manifold, Upper Left 05700-004-57-22
5 1 Wash Manifold, Upper Right 05700-004-57-21
6 4 O-ring, 2 1/2" 05330-003-73-72
7 1 Wash Manifold, Lower Left 05700-004-57-24
8 1 Wash Manifold, Lower Right 05700-004-57-23
9 2 O-ring, 2 11/16" 05330-003-73-71
10 12 Screw, 6-40 x 3/8" 05305-002-63-49
11 12 Lanyard, 6" 05340-011-72-46
12 1 Wash Pump Manifold 05700-004-63-71
13 12 Locknut, 10-32 with Nylon Insert 05310-373-02-00
14 1 Elbow, 1 1/2" Brass, 90-degree 04730-206-32-00
15 1 Valve, Ball 1 1/2" 04820-111-71-46
16 2 Nipple, 1 1/2" Brass 04730-207-40-00
17 1 Drain Handle 05700-004-62-26
18 1 Fitting, 1 1/2" 04730-002-74-06
19 3 Connector, 2" No Hub 04730-002-66-87
20 1 Tee, 2" 04730-002-66-09
21 1 Fitting 04730-004-52-94
22 1 Tube, CVPC, 2" x 10 1/2" 05700-004-73-98
23 1 Reducing Tee 04730-004-63-80
24 1 Tube, CVPC, 2" x 11 1/2" 05700-004-64-38
25 1 Tube, CVPC, 2", Drain Right Side 05700-004-64-39
26 2 Tube, CVPC, 2", Drain Left Side 05700-004-66-94
27 1 Tee, 1 1/2" 04730-011-69-93
28 1 Reducer, 1 1/2" to 1/4" 04730-002-55-76
29 1 Fitting, 1/4" 04730-011-95-41
30 1 Union, 1 1/2" 04730-212-08-34
