07610-004-81-74-A
35
PRE-WASH CONTROL BOX
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Terminal Board 05940-002-78-97
2 22 Nut, Hex 10-32 05310-004-40-48
3 10 Screw, 10-32 x 3/4" 05305-011-62-17
4 4 Screw, 6-32 x 1 3/4" 05305-004-36-67
5 4 Nut, Lock 6-32 Hex with Nylon Insert 05310-373-03-00
6 1 Terminal Block, 3-pole 05940-011-48-27
7 1 Relay, 2-Pole 05945-111-35-19
8 1 Din-rail, 3" 05700-011-84-65
9 1 Bushing, Snap 05975-003-10-46
10 1 Panduit Top, 1 1/2" x 20 3/4" 05700-002-87-24
11 2 Nut, 6-32 Plated 05340-118-04-00
12 2 Screw, 6-32 x 1/2" 05305-004-23-63
13 1 Foam Insulation, Lower Tub 05700-004-75-55
14 1 Panduit Bottom, 1 1/2" x 3" x 10" 05700-004-65-17
15 1 Panduit Bottom, 1 1/2" x 3" x 8" 05700-004-65-18
16 1 Fan 05999-004-19-46
17 1 Control Box 05700-004-73-68
18 2 Connector, 16-pin Mount 05940-004-73-27
19 2 Connector, 10-pin Mount 05940-004-73-28
20 2 Connector, 8-pin Mount 05940-004-73-29
21 2 Connector, 16-pin Receptacle 05940-004-73-43
22 2 Connector, 8-pin Receptacle 05940-004-73-44
23 2 Connector, 10-pin Receptacle 05940-004-73-45
24 1 Cover, Connector Hole, 8-pin 05940-004-73-47
25 1 Connector, 16-pin Receptacle 05975-003-35-32
26 1 Connector, 10-pin Receptacle 05975-004-35-29
27 1 Cover, Control Box 05700-004-74-07
28 2 Fitting, Nut and Cap 05975-205-43-00
29 1 Fitting 05975-011-49-03
30 1 Overload 05945-004-25-81
31 1 Contactor, AC, 100 V 05945-004-25-78
32 1 Cover, Connector Hole, 10-pin 05700-004-83-63
