07610-004-81-74-A
28
ITEM QTY DESCRIPTION PART NUMBER
1 1 Upper Rail Two 05700-004-61-01
2 1 Screen Rail Three 05700-004-65-53
3 2 Lower Rail 05700-004-61-02
4 1 Screen Rail Two 05700-004-65-52
5 1 Adjuster, Conveyor, Left 05700-004-61-05
6 1 Screen Rail One 05700-004-65-51
7 2 Bolt, 3/8-16 x 5" 05700-003-52-34
8 2 Side Cover 05700-004-66-80
9 1 End Cover, Top 05700-004-66-79
10 1 Adjuster, Conveyor, Right 05700-004-61-08
11 2 Snap Bushing 05975-003-10-46
12 1 Stop Switch 05930-004-72-99
13 1 Start Switch 05930-004-72-98
14 1 End Cover 05700-004-66-78
15 1 Runo 05700-004-61-18
16 1 Upper Rail One 05700-004-61-03
17 2 Sensor 05945-003-05-69
18 2 Optical Cover 05700-004-65-48
19 1 Damper 05700-004-72-59
20* 1
Shroud, L-R
Complete Shroud Assembly, L-R (Items 17–20)
Shroud, R-L
Complete Shroud Assembly, R-L (Items 17–20)
05700-004-60-85
05700-004-78-18
05700-004-76-28
05700-004-79-82
LOAD SECTION
PARTS
*If Load Expansion is used, Shroud is located on the expansion section.
