07610-004-81-74-A
8
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
Local codes may require more stringent protection than what is displayed here and on the data plate. Always verify with
your electrical service contractor that your circuit protection is adequate and meets all applicable national and local codes.
Numbers in this manual are for reference and may change without notice.
Imbalanced wild leg goes to L3. Also see the Motor Rotation section.
NOTICE
i
Electric Machines with No Blower/Dryer
208 V/60 Hz/3-Phase
Heater kW Pump HP 208 V MCA MOP
Wash Heater & Pump Section 27 3 84.1 A 86.4 A 95 A
Power Rinse Heater & Pump Section 30 3 92.5 A 94.8 A 100 A
Motors, Pre-wash Pump, & Controls - 3 11.3 A 13.6 A 20 A
Booster Option 27 - 74.9 A 76.2 A 80 A
208 V/60 Hz/3-Phase
Heater kW Pump HP 208 V MCA MOP
Wash Heater & Pump Section 27 3 84.1 A 86.4 A 95 A
Power Rinse Heater & Pump Section 30 3 92.5 A 94.8 A 100 A
Motors, Pre-wash Pump, Controls, & Blower/Dryer 9 3 41.5 A 43.8 A 50 A
Booster Option 27 - 74.9 A 76.2 A 80 A
230 V/60 Hz/3-Phase
Heater kW Pump HP 230 V MCA MOP
Wash Heater & Pump Section 27 3 70.8 A 73.0 A 80 A
Power Rinse Heater & Pump Section 30 3 77.8 A 79.9 A 85 A
Motors, Pre-wash Pump, & Controls - 3 10.7 A 12.9 A 20 A
Booster Option 27 - 65.0 A 66.3 A 70 A
460 V/60 Hz/3-Phase
Heater kW Pump HP 460 V MCA MOP
Wash Heater & Pump Section 27 3 35.4 A 36.5 A 40 A
Power Rinse Heater & Pump Section 30 3 38.9 A 40.0 A 45 A
Motors, Pre-wash Pump, & Controls - 3 5.5 A 6.6 A 15 A
Booster Option 27 - 32.5 A 33.8 A 35 A
Electric Machines with Blower/Dryer
230 V/60 Hz/3-Phase
Heater kW Pump HP 230 V MCA MOP
Wash Heater & Pump Section 27 3 70.8 A 73.0 A 80 A
Power Rinse Heater & Pump Section 30 3 77.8 A 79.9 A 85 A
Motors, Pre-wash Pump, Controls, & Blower/Dryer 9 3 36.6 A 38.8 A 45 A
Booster Option 27 - 65.0 A 66.3 A 70 A
Electrical tables show base machine with Pre-wash section and base machine with Pre-wash and Blower/Dryer sections
and are for reference only. Use machine data plate for electrical specs specic to machine that was ordered.
NOTICE
