PARTS
HH-E VER PLUMBING
ITEM QTY DESCRIPTION PART NUMBER
1 1 Vacuum Breaker, 1/2" Brass 04820-003-06-13
2 1 Nipple, 1/2" x 6" Brass 04730-003-62-38
3 2 Tee 04730-002-22-56
4 1 Pressure Transducer 05945-004-17-01
5 1 Elbow, 90-Degree 1/4" x 1/4" 04730-003-77-83
6 1 Rinse Injector 09515-004-94-21
7 2 Plug, 1/8" NPT Brass 04730-209-07-37
8 1 Injector Plate 05700-002-04-71
9 3 Elbow, 90-Degree 1/2" Brass 04730-011-42-96
10 2 Hose, Black, 1" ID, 1 1/2" Long 05700-004-68-24
11 2 Fitting, 1" x 1/2" Brass 04730-004-68-25
12 4 Nipple, 1/2" Close Brass 04730-207-15-00
13 4 Clamp, 13/16" x 1 1/2" 04730-719-06-09
14 1 Fast-acting Probe 06685-004-75-99
15 1 Union, 1/4" Modied 05700-001-16-52
16 3 Elbow, 90-Degree 1/2" Street Brass 04730-206-08-00
17 1 Hose, 1/2" x 5" 05700-005-00-14
18 1 Hose, 1/2" x 48 1/2" 05700-005-00-27
19 1 Hose, 1/2" x 10" 05700-004-67-84
20 1 Hose, Coil Drain 1/2" 05700-005-01-99
21 1 Y-strainer, 1/2" 04730-217-01-10
22 1 Coupling, 1/2" 05700-004-47-97
23 1 Solenoid Valve, 1/2" 04810-003-71-56
24 1 Flow Limiter, 1/2" 04730-004-67-76
25 1 Tee, 1/2" x 1/2" x 1/4" 05700-005-02-30
26* 1 Rinse Pump 05700-004-67-91
27 1 Thermistor Probe 06685-004-34-58
28* 1
Harness
Cable, Braided (Not Shown)
05700-004-33-62
05700-004-33-59
29 1 Hose, 1/2" x 24" 05700-005-01-97
30 1 Hose, 1/2" x 30 1/2" 05700-005-01-98
