CONTROL PANEL, 460 V
PARTS
ITEM QTY DESCRIPTION PART NUMBER
1 1 Bracket, Timer & I/O Board 05700-004-60-47
2 1 I/O Module 05945-005-01-56
3 1 Relay 05945-111-89-75
4 2 Contactor, 4-Pole, 208-240 V 30 A 05945-004-43-74
5 1 Fuse Holder, 6-pole 05920-002-42-13
6 1 Bracket, Fuse Strip 05700-002-42-03
7 1 Fuse Holder, 2-pole 05920-401-03-14
8 10
Locknut, 10-24 Hex with Nylon Insert
05310-373-01-00
9 10 Washer, Flat 05311-173-02-00
10 3
Locknut, 10-24 Hex with Nylon Insert
05310-373-03-00
11 1 Panel, Electrical Main 05700-004-84-06
12 1
Fuse Holder, Single
05920-011-72-89
13 1 Transformer, 150 V 05950-004-71-04
14 1 Fuse, 10 A 05920-004-89-65
15 2
Fuse, Fast-acting, 1 A
05999-004-47-87
16 1
Overload
05945-002-65-02
17 1
Motor, Contactor
05945-002-65-00
18 1
Din-rail, 3"
05700-011-84-65
19 3
Fastener, 10-32
05340-111-47-27
20 2 Screw, 10-32 x 1/2" 05305-011-44-52
21 6
Fuse, Slow-acting, 200 mA
05999-004-44-33
22 1
Decal, Dispenser Connection, 460 V
09905-004-43-81
23 1
Terminal Board
05940-002-78-97
24 1
Power Supply (VER)
05950-004-81-79
