42
07610-004-37-13-S
Use teon tape on threads. Do NOT use "pipe dope."
ITEM QTY DESCRIPTION PART NUMBER
1 1 Elbow, 1/2" 90-Degree 04730-206-08-00
2 2 Adapter, 1/2" x 1/2" 04730-004-97-23
3 1 Adapter, Male 04730-401-03-01
4 1 Tube, Copper 1/2" x 22" 05700-003-32-16
5 1 Vacuum Breaker 04820-003-06-13
6 2 Plug, 1/4" Brass 04730-209-01-00
7 1 Pipe Clamp 05700-011-38-62
8 1 Injector Adapter 05700-031-40-44
9 1 Check Valve 04820-111-51-14
10 1 Fitting, Outlet Elbow 04820-111-51-18
11 1 Nut, Tube 04730-011-59-45
12 1 Bushing, 1/4" x 1/8" 04730-003-05-61
13 1 Valve, 1/2" 208/60 04810-003-71-56
14 1 Hose Adapter 04720-004-24-68
15 1 Elbow, 1/2" 04730-406-31-01
16 1 Copper Tube 1/2" x 3" 05700-003-36-25
17 1 Union, 1/2" 04730-412-05-01
18 1 Elbow, 1/2" 90-Degree 04730-406-32-01
19 1 Tee, 1/2" x 1/2" x 1/4" Female 04730-411-25-01
20 1 Copper Pipe, 4 3/4" Long 05700-002-91-02
21 1 Adapter, 1/2" Male 04730-011-59-53
22 2 Rinse Hub Weldment 05700-021-38-31
23 2 Pipe Clamp (Side of Unit) 05700-000-35-05
24 1 Fitting, 1/2" x 1/4" 05700-004-36-74
25 1 Pressure Transducer 05945-004-84-32
26 1 Thermistor Probe, 4" 06685-004-34-58
NOTICE
HT PLUMBING
PARTS
