07610-004-99-71-B
2
SPECIFICATIONS
DIMENSIONS
29 3/4
[756 mm]
12
[304 mm]
CLEARANCE
24 1/4
[615 mm]
LEGEND
A - Electrical Connection
B - Water Inlet (with 5' Hose)
(3/4" Male GHT, connect to true
1/2" ID line, 40–90 °F)
C - Drain Connection
(5/8" ID, install into MIN
1 1/2" Drain with Air-gap)
D - Chemical Port
All dimensions from the floor
can be increased 1” using the
machine’s adjustable feet.
*Back and side views shown with back panel removed.
14 [356 mm]
DOOR OPEN
26 7/8
[692 mm]
1/4
[7 mm]
40 7/8
[1037 mm]
4 3/8
[110 mm]
3
[76 mm]
3 5/8
[91 mm]
10 1/4
[261 mm]
12 1/2
[378 mm]
8 1/2
[216 mm]
*
2 7/8
[73 mm]
7 3/8
[187 mm]
2 1/2
[64 mm]
14 3/8
[365 mm]
*
Install Machine
Drain Hose into
1 1/2 [38 mm]
MIN Floor Drain
or Sink
Do NOT install
Drain Hose to
“bottom” of Floor
Drain or Sink.
This can cause
splashback.
