07610-003-92-84-P
53
Ball Stopper
05700-121-35-54
Blue Chemical Tubing (120")
05700-011-37-17
Red Chemical Tubing (120")
05700-011-37-15
White Chemical Tubing (120")
05700-011-37-13
Chemical Tubing Stiffener
05700-002-66-49
Bulk Head Fitting
04730-011-45-21
Flanged Bullet Foot
(optional)
05340-002-34-86
Standpipe Assembly, XL-E/XL-E-LTH
05700-003-78-51
Standpipe Assembly, XL HH
05700-004-27-31
Sump Strainer
05700-002-06-25
MISCELLANEOUS PARTS
PARTS
Water Pressure Regulator, 3/4"
06685-011-58-22
Water Arrestor, 1/2”
06685-100-05-00
Tee, 3/4” x 3/4” x 1/2”
04730-211-06-00
Nipple, 3/4” NPT, Close, Brass
04730-207-34-00
Chemical Tubing, Wye Fitting
04730-003-36-14
Tygoprene Tubing, Wye Fitting
05700-003-53-26
Parts not shown to scale in relation to each other.
