07610-003-92-84-P
35
1 1
Control Box Assembly, 115 V
Control Box Assembly, 208 V
05700-004-01-65
05700-004-16-66
2 1 Hood, Weldment 05700-004-08-68
3 10 Locknut, 1/4-20 with Nylon Insert 05310-374-01-00
4 2 Hood Support 05700-002-78-99
5 6 Bolt, 1/4-20 x 1/2” 05305-274-02-00
6 12 Washer, SS 1/4” 05311-174-01-00
7 2 Bracket, Cantilever Support 09515-003-15-64
8 6 Wear Button 05700-011-88-01
9 1 Bracket, Plumbing Support 05700-003-24-25
10 1 Y-Strainer, 3/4" NPT Brass 04730-717-02-06
11 1 Nipple, 3/4" x 3” Brass 04730-011-38-29
12 1
Solenoid Valve, 3/4”, 115 V
Solenoid Valve, 3/4”, 208 V
04810-100-53-00
04810-100-03-18
13 1 Elbow, 3/4” Street Brass 04730-206-04-34
14 1 Air-gap 05700-004-34-42
15 1 Gasket, Air-gap 05330-002-14-48
16 1 Reed Switch 05930-002-36-80
17 4 Spacer, Sleeve Hood 05700-003-55-15
18 1 Nipple, 3/4" x 1 3/8" Brass 04730-207-34-00
ITEM QTY DESCRIPTION PART NUMBER
XL-E HOOD ASSEMBLY
PARTS
Machines with serial numbers before 17C331529 have 1/2" plumbing. Click here to open the manual which
shows the 1/2" plumbing.
NOTICE
