07610-003-92-84-P
30
ITEM QTY DESCRIPTION PART NUMBER
High Hood Control Box Complete Assembly 05700-004-25-41
1 1 Control Box Weldment 05700-003-81-49
2 3 Light, Red 05945-504-07-18
3 1 Light, Green 05945-504-08-18
4 1 Switch, Carling 05930-301-21-18
5
1 Counter, 115 V 05990-111-35-38
1 Counter, 208 V 05990-111-47-42
6 2 Screw, 4-40 x 1/4" Phillips Pan Head w/Washer 05305-002-32-38
7 1
Chemical Feeder Pump Assembly, 14 RPM (208 V Units)
Chemical Feeder Pump Assembly, 14 RPM (115 V Units)
05700-003-31-86
05700-003-25-03
8 1 Block, Altech Terminal 05940-500-09-61
9
1 Contactor, 115 V 05945-109-05-69
1 Contactor, 208 V 05945-002-74-20
10 1 Terminal Board 05940-021-94-85
11 1 Lug, Panduit Ground 05940-200-76-00
12 1 Spacer, Terminal Block 05700-011-40-05
13 18 Nut, Lock 10-24 SS Hex w/Nylon Insert 05310-373-01-00
14 11 Nut, Lock 6-32 Hex w/Nylon Insert 05310-373-03-00
15 1 Fitting, T&B 1/2" Plastic 05975-011-45-13
16 2 Fitting, T&B 1/2" 45-degree Plastic 05975-011-45-23
17 1 Decal, Copper Conductors 09905-011-47-35
18 1 Decal, Delime/Normal 09905-011-34-96
19 1 Grommet, 7/8" Split Helco 05975-200-40-00
20 1 Grommet, 1/2" OD x 0.38" ID 05325-011-46-73
21 1 Decal, Power Connection 09905-011-47-64
22 2
Chemical Feeder Pump Assembly, 36 RPM (208 V Units)
Chemical Feeder Pump Assembly, 36 RPM (115 V Units)
05700-003-78-74
05700-003-25-02
23 1 Switch, Carling 05930-111-38-79
24 1 Lock, Control Box 05340-102-01-00
25 2 Switch, Pressure 06685-003-36-13
26 3 Switch, Prime 05930-011-49-54
27 1 Decal, Lower Control 09905-004-00-06
28 1 Bracket, Timer Mounting 05700-004-08-77
29
1 Relay, Pole 115 V 05945-111-35-19
1 Relay, Pole 208 V 05945-111-47-51
XL HH CONTROL BOX
PARTS
