Je bekijkt pagina 34 van 64
07610-003-92-84-P
28
ITEM QTY DESCRIPTION PART NUMBER
8 1 Contactor, 30 A 05945-004-43-74
9 1 Thermostat, Elan Electric (Dual) 06685-004-17-27
10 1 Terminal Board 05940-021-94-85
11 1 Terminal Block, 3-Pole 05940-011-48-27
12 1 Contactor, 30 A 05945-002-74-20
13 1 Counter, Plastic 05990-111-47-42
14 1 Relay, Top Mount 05945-111-47-51
15
15a
1
8
Timer
Microswitch, Timer
05945-111-48-25
05930-011-65-81
16 1 Lug, Ground 05940-200-76-00
17 6 P-clamp, 1/4" ID 05975-002-61-42
18 2 Switch, Pressure 06685-003-36-13
19 1 Switch, On/Off/Fill 05930-111-38-79
20 3 Switch, Chemical Prime 05930-011-49-54
21 1 Switch, Normal/Delime 05930-301-21-18
22 1 Switch, Cycle 05930-301-49-00
23 1 Light, Amber 05945-111-44-44
24 3 Light, Red 05945-504-07-18
25 1 Light, Green 05945-504-08-18
26 1 Decal, Timer Cam Operation 09905-011-37-21
27 1 Decal, Ground 09905-011-86-86
28 1 Decal, Normal/Delime 09905-011-34-96
29 1 Temperature Gauge 06685-004-31-46
30 3 Fitting, 1/2", 45-degree Plastic 05975-011-45-23
31 1 Decal, Wash/Rinse 09905-002-82-46
32 14 Locknut, 6-32 Hex with Nylon Insert 05310-373-03-00
33 2 Screw, 4-40 x 1/4" with Washer 05305-002-32-38
34 1 Grommet, 1/2" OD x .38” ID 05325-011-46-73
35 21 Locknut, 10-24 Hex with Nylon Insert 05310-373-01-00
36 1 Decal, Copper Conductors 09905-011-47-35
37 1 Bushing, Split 05975-200-40-00
1 Lock, Control Box (Not Shown) 05340-102-01-00
XL-E-LTH CONTROL BOX
PARTS
