RINSE
HEATER
MODEL VOLTS PH HZ RATINGS AMPS CIRCUIT
AJX-44CE 208 1 60 N/A 96.8 A 125 AMP
AJX-44CE 230 1 60 N/A 88.6 A 125 AMP
AJX-44CE 208 3 60 N/A 56.7 A 80 AMP
AJX-44CE 230 3 60 N/A 51.9 A 70 AMP
AJX-44CE 460 3 60 N/A 26.0 A 35 AMP
AJX-44CS 208 1 60 N/A 10.3 A 15 AMP
AJX-44CS 230 1 60 N/A 10.3 A 15 AMP
AJX-44CS 208 3 60 N/A 6.7 A 15 AMP
AJX-44CS 230 3 60 N/A 6.7 A 15 AMP
AJX-44CS 460 3 60 N/A 3.4 A 15 AMP
AJX-66CE 208 1 60 N/A 102.8 A 150 AMP
AJX-66CE 230 1 60 N/A 94.6 A 125 AMP
AJX-66CE 208 3 60 N/A 60.1 A 80 AMP
AJX-66CE 230 3 60 N/A 55.3 A 70 AMP
AJX-66CE 460 3 60 N/A 27.7 A 35 AMP
AJX-66CS 208 1 60 N/A 16.3 A 25 AMP
AJX-66CS 230 1 60 N/A 16.3 A 25 AMP
AJX-66CS 208 3 60 N/A 10.1 A 15 AMP
AJX-66CS 230 3 60 N/A 10.1 A 15 AMP
AJX-66CS 460 3 60 N/A 5.1 A 15 AMP
AJX-80CE 208 1 60 N/A 105.3 A 150 AMP
AJX-80CE 230 1 60 N/A 97.1 A 125 AMP
AJX-80CE 208 3 60 N/A 62.3 A 80 AMP
AJX-80CE 230 3 60 N/A 57.5 A 80 AMP
AJX-80CE 460 3 60 N/A 28.8 A 40 AMP
AJX-80CS 208 1 60 N/A 18.8 A 25 AMP
AJX-80CS 230 1 60 N/A 18.8 A 25 AMP
AJX-80CS 208 3 60 N/A 12.3 A 20 AMP
AJX-80CS 230 3 60 N/A 12.3 A 20 AMP
AJX-80CS 460 3 60 N/A 6.2 A 15 AMP
AJX-44 & AJX-54 Series Technical Manual 7610-003-60-98
Issued: 01-19-2009 Revised: 01-30-2009
SECTION 1: SPECIFICATION INFORMATION
ELECTRICAL REQUIREMENTS
3
NOTE: Typical Electrical Circuit is based upon (1) 125% of the full amperage load of the machine and (2) typical fixed-trip cir-
cuit breaker sizes as listed in the NEC 2002 Edition. Local codes may require more stringent protection than what is displayed
here. Always verify with your electrical service contractor that your circuit protection is adequate and meets all applicable
national and local codes. These numbers are provided in this manual simply for reference and may change without notice at
any given time.
AMPS CIRCUIT
82.4 A 125 AMP
75.5 A 100 AMP
48.4 A 60 AMP
44.4 A 60 AMP
22.3 A 30 AMP
10.3 A 15 AMP
10.3 A 15 AMP
6.7 A 15 AMP
6.7 A 15 AMP
3.4 A 15 AMP
88.4 A 125 AMP
81.5 A 125 AMP
51.8 A 70 AMP
47.8 A 60 AMP
24.0 A 30 AMP
16.3 A 25 AMP
16.37 A 25 AMP
10.1 A 15 AMP
10.1 A 15 AMP
5.1 A 15 AMP
90.9 A 125 AMP
84.0 A 125 AMP
54.0 A 70 AMP
50.0 A 70 AMP
25.0 A 30 AMP
18.8 A 25 AMP
18.8 A 25 AMP
12.3 A 20 AMP
12.3 A 20 AMP
6.2 A 15 AMP
With 18kW Wash
Tank Heater
With 15kW Wash
Tank Heater
