Iris Ohyama SCD-130P handleiding
Handleiding
Je bekijkt pagina 14 van 76
Black SCD-130P
EN
14
Soft roller brush if stains becomes
obvious
If stains becomes obvious,
1
Remove the brush cover
• To remove the brush cover, pull the brush cover
toward yourself while holding down the brush
cover’s hook.
Brush cover
2
Remove the soft roller brush
3
Wash the soft roller brush with water
* Remove dust adhering to the soft roller brush with
scissors or tweezers before washing it with water.
• Dry the brush well after washing it with water.
4
Attach the soft roller brush
5
Attach the brush cover
①
Fit the tip of the brush cover to the inside of the front
end of the oor head.
②
Attach the brush cover by pressing it down until you
hear a click sound.
①
②
Dust cup
Clean about once in two months
1
Remove the dust cup from the main unit
• The dust cup can be removed by sliding the dust-
cup removing button. Remove the dust cup by
pulling it toward yourself.
Dust cup
removal
button
* Dispose of dust in the dust cup, if any.
2
Remove the upper case of the dust cup
• Remove the upper case of the dust cup by turning
it until ▼of the upper case lines up with ▲
of the
lower case.
Maintenance
(continued)
