Charging Dock for NS 2 Joypad
Product Manual (PG-SW2185)
Product Features:
Product Instructions:
Notes:
Product List:
Product Technical Parameters:
Product Diagram:
1.Assemble the two parts of the charging dock, remove
the protective film from the surface of the host fixing
sticker, connect the charging dock to the original NS 2
dock, and attach the product tightly to the NS 2 dock.
2.After the product is powered on, the 4 Joypad controller
slot charging indicators will light up blue;
3.Insert the Joypad controller into any slot for charging.
The corresponding indicator light will be steady orange
during charging, and the corresponding indicator light will
be steady blue when fully charged;
1.This product is a charging dock used with the original NS
2 dock for the NS 2 Joypad controller;
2.Equipped with 4 charging slots, supporting charging 1 to
4 Joypad controllers simultaneously;
3.The original NS 2 dock provides power input for the product;
4.Equipped with a USB 2.0 expansion port, supporting
DC5V power output and data transmission functions
(supports only NS Pro controllers);
5.Equipped with 4 charging indicators to display the
controller's charging status in real-time;
6.Usage scenario: Used with the original NS 2 Joypad
controller and dock. It is necessary to use the original NS2
power adapter and use it indoors without a strong magnetic
environment.
Please do not store this product in a humid or high-tem-
perature place.
Please do not knock, drop, puncture, or attempt to
disassemble this product to avoid unnecessary damage to
the product.
Non-professionals should not disassemble this product,
otherwise, it will not be covered by the after-sales warranty
service.
Please do not discard this product at will. It must be
recycled by a qualified organization.
Do not use it for charging Joypad controllers other than the
original NS 2.
When using a wired connection with the NS PRO controller,
it is necessary to use a reliable USB cable to avoid poor
connection or disconnection.
Input Voltage: DC5V
Single Controller Charging Current: 200mA
Charging Slot x4
NS 2 Dock Power Indicator
USB 2.0 Plug
Charging Indicator
Insert Part 1 into Part 2's
USB port as shown
Remove the protective film
from the fixing sticker.
Connect the product to the
NS 2 dock and firmly attach
it to the dock.
Part 2
Part 1
USB 2.0
Expansion
Port
Charging Dock x1 User Manual x1
