15
10 USB Console Ports Wired USB keyboard and mouse are connected into these ports. The USB console
keyboard port (lower port) and mouse port (upper port) are only compatible with standard
wired USB keyboards/mice, standard wired USB keyboards/mice via a USB hub, and the
HID functions of a composite device.
Note:
1. The console USB keyboard and mouse ports are interchangeable. User can
connect a keyboard to the mouse port and vice versa. However, for optimal opera-
tion, it is recommended that the USB keyboard connected to the console’s USB
keyboard port and the USB mouse connected to the console’s USB mouse port.
2. For security purposes, IOGEAR Secure KVM Switch series do not support wireless
keyboards and mice. Do not attempt to connect a wireless keyboard and mouse to
the switch in any case.
3. Non-standard keyboards/mice with integrated USB hubs and/or other USB-inte-
grated devices may not be fully supported due to the strict security standards and
policy for IOGEAR Secure KVM Switch. If supported, only basic (HID) keyboard/
mouse operations will function.
4. Multimedia keys on the keyboard will not function due to security policy.
5. Num Lock, Caps Lock, and Scroll Lock LED on keyboards will not function due to
security policy.
6. USB HID device lter is congurable by authorized administrators for trusted
devices (only the USB console mouse port is applicable for setting specic blocked
devices). Please refer to the Administrator Guide for details.
11 Remote Port Selector
(RPS) Port
Connect the Remote Port Selector (RPS). The RPS requires a separate purchase
12 Video LED(s) Video LED lights green when the video connection is established
Video LED ashes when a non-qualied monitor is connected
Note:
With the Dual View (dual monitor) models, each console video connection has one Video
LED
13 Console Monitor Port(s) Console monitor’s cables are connected into these ports
Note:
IOGEAR Secure KVM Switch Dual View models has two console monitor ports
14 KVM Port Section Connect IOGEAR proprietary KVM cables from the computers into these ports
15 KVM Audio Ports Connect audio cable from the connected computers into these ports
Note:
Only speaker connections are allowed. The use of analog microphones or line-in audio
devices is strictly prohibited
16 KVM USB Ports Connect the USB cable for keyboard/mouse from the the connected computer into these
ports
17 USB Smart Card / CAC
(Common Access Card)
Reader Port
Connect the cable for USB Smart Card/CAC reader from the connected computer into
these ports
18 Power Switch This is a standard rocker switch that powers the IOGEAR Secure KVM Switch on and o
19 Power Socket Connect the included AC power cord into this socket
